ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP (i20NB)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
34 1021840 HEX BOLT M8×40 2
35 1422821 LOCK WASHER M8 8
36 1421828 FLAT WASHER M8×
28×3 2
37 6210111 CLAMP, DRAIN HOSE 1
38 1221515 PH SCREW M5×15 2
39 8114712 MICRO SWITCH 1
40 1434300 LOCK WASHER, TOOTH, M3 2
41 1021320 SCREW M3×20 2
42 8134022 BRACKET,SWITCH 1
43 8114402 BRACKET, SPRING 1
44 1521616 SCREW M6X16, HEX SCOKET 2
45 8114300 ACTUATOR 1
46 1534608 SET SCREW M6 ×8 4
47 1535630 SET SCREW M6 ×30 1
48 8114306 SPRING 1
49 8114101 SHAFT 1
50 8134300 LEVER, BAIL 1
51 1123507 LOCK NUT M5 2
52 8134701
000271-000527
MAIN CONTROLLER 1
53 8134021 REAR PLATE, CONTROL CONSOLE 1
54 1421824 FLAT WASHER M8× 24×2 6
55 1021820 HEX BOLT M8×20 6
56 1221525 PH SCREW M5 X 25 2
