Ice i20NBT Operator's & Parts Manual

26
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP（i20NBT / i24BT）
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
40 1422821 LOCK WASHER M8 12
41 1421828 FLAT WASHER M8×
∮
28×3 2
42 1021630 HEX HEAD BOLT M6×30,SS 1
43 8134082 CABLE, SQGE LIFT 1
44 8014101 LIFTING ROPE SPACER 1
45 1021512 HEX HEAD BOLT M5×12,SS 1
46 1421515 FLAT WASHER M5×
∮
15×1.0 1
47 1123608 LOCK NUT M6 3
48 8014012 BAFFLE 1
49 8113111 NYLON FLAT WASHER
∮
12.9×
∮
25.4×0.8 1
50 1121605 HEX NUT M6 2
51 8134501 BRACKET 1
52 8134081 SLEEVEE 1
53 1421132 FLAT WASHER M12×
∮
32×1.5 1
54 8134080 SQUEEGEE LIFTING HANDLE 1
55 8113104 BALL KNOB M8 1
56 1222641 SUNK HEAD SCREW M6 X 40 2
57 8210112 HOOK, POWER CORD 2
58 8014054 STRAIN RELIEF 1
59 6210111 CLAMP, DRAIN HOSE 1
60 1023612 HEX BOLT M6 X 12, COPPER 8
61 1422616 LOCK WASHER, M6 13
62 1423612 FLAT WASHER M6×
∮
12×1, COPPER 8
63 8144790 MAIN CONTROLLER, i20NBT 1
64 8134070 REAR PLATE, CONTROL CONSOLE 1
65 1421824 FLAT WASHER M8×
∮
24×2 10
66 1021820 HEX BOLT M8×20 10
67 1221620 PH SCREW M6×20 2
68 8114712 MICRO SWITCH 1
69 8124743 MICRO SWITCH 1
70 1021320 SCREW M3 X 20 4
71 8134022 BRACKET,SWITCH 1
72 8114402 BRACKET, SPRING 1
73 1521616 SCREW M6X16, HEX SCOKET 2
74 1534608 SET SCREW M6 ×8 4
75 8134300 LEVER, BAIL 1
76 8114300 ACTUATOR 1
77 8114306 SPRING 1
78 1535630 SET SCREW M6 ×30 1
79 8114101 SHAFT 1
