ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
FRAME & TRANSAXLE GROUP（i20NBT /i24BT）
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 1021820 HEX BOLT M8×20 12
2 1422821 LOCK WASHER M8 15
3 1421824 FLAT WASHER M8×
∮
24×2 5
4 8145100 MAIN FRAME 1
5 1421618 FLAT WASHER M6×
∮
18×1.6 4
6 1123608 LOCK NUT M6 3
7 8115300 BRACKET, PEDAL LOCKING 1
8 1421124 FLAT WASHER M12×
∮
24×2.5 4
9 1123115 LOCK NUT M12 4
10 8119003 SOLENOID VALVE, 24VDC 1
11 1421409 FLAT WASHER M4×
∮
9×0.8 2
12 1422411 LOCK WASHER M4 2
13 1221412 SCREW M4×12 4
14 8115004 SPIRNG 1
15 8135010 BRACKET, SQGE LIFT 1
16 8115405 SLEEVE, P/M 4
17 8135001 PLASTIC THRUST WASHER M12×
∮
30×1.5 4
18 1421132 FLAT WASHER M12×
∮
32×1.5 4
19 1021230 HEX BOLT M12 ×30 2
20 1645324 COTTER 3.2 ×24 1
21 8115003 PIN 1
22 8114511 BALL JOINT M6 1
23 8115001 BRACKET, SQGE MNTG 1
24 8115203 COVER, WHEEL 2
25 1021816 HEX BOLT M8×16 3
26 1421828 FLAT WASHER M8×
∮
28×3 2
27
8125200 WHEEL, 8 INCH 2
8225200 AIR FILLED WHEEL, 8 INCH, KIT 2
8225210 FOAM FILLED WHEEL, 8INCH, KIT 2
28 1421816 FLAT WASHER M8×
∮
16×1.6 10
29 1436019 RETAINING RING 19 2
30 8125403 WOODRUFF KEY 2
31
8125410 TRANSAXLE, KIT 1
8116011 CARBON BRUSH, DRIVE MOTOR 2
32 1123810 LOCK NUT M8 10
33 8117007 NYLON WASHER
∮
12.9×
∮
24×2.5 4
34 8115404 BEARING, JOURNAL 2
35 8145001 BUSHING 2
36 1021840 HEX BOLT M8 ×40 2
37 1211325 SCREW M3×25 2
38 1434300 LOCK WASHER, TOOTH, M3 2
39 8014071 MICRO SWITCH 20A 1
40 8115500 CASTER, SWIVEL, 80MM 2
41 8210118 STATIC STRAP 1
