Ice i20NBT Operator's & Parts Manual

40
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
ORBITAL HEAD LIFT GROUP (i20NBT-OB)
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8137006 NON-SLIP MAT 1
2 8137100 BRACKET, SCRUB HEAD LIFT 1
3 8133151 BUMPER 3
4 1123810 LOCK NUT M8 7
5 1021820 HEX HEAD BOLT M8×20 2
6 8115405 SLEEVE, P/M 2
7 8115404 BEARING, JOURNAL 2
8 8117007 NYLON WASHER
∮
12.9×
∮
24×2.5 4
9
1435013 WAVE WASHER 4
10
1421824 FLAT WASHER M8×
∮
24×2 2
11
1021830 HEX HEAD BOLT M8×30 2
12
8146530 BRACKET, ORBITAL HEAD LIFT 1
