Ice i24BT Operator's & Parts Manual

22
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
CONTROL CONSOLE GROUP（i20NB）
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
8114709 KEY SWITCH 1
8114752 KEY 1
2 8134724 CONTROL PANEL DECAL, i20NB 1
3 1221512 SCREW M5×12 17
4 1422513 LOCK WASHER M5 6
5 1421510 FLAT WASHER M5×
∮
10×1.0 13
6 8134720 CONTROL PANEL, i20NB 1
7 8134015 GASKET 1
8
8134734 CONTROL PANEL PCB, i20NB (AGM / EN) 1
8134736 CONTROL PANEL PCB, i20NBT(WET FLOODED/ EN) 1
9 1221306 SCREW M3×6 7
10 8134005A CONTROL HOUSING, i20NB 1
11 1021616 HEX BOLT M6 X 16 5
12 1421618 PLAIN WASHER M6×
∮
18×1.6,SS 10
13 8114008 BRACKET, SQGE STORAGE 1
14 8310740 CIRCUIT BREAKER, 5A 1
15 8134006 PLATE, CIRCUIT BREAKERS MNTG 1
16 8144025 LABEL, CIRCUIT BREAKER 1
17 1221515 PH SCREW M5×15 4
18 1123507 LOCK NUT M5 2
19 1123305 LOCK NUT M3 4
20 8113010 BRACKET, CONNECTOR MTG 1
21 8113020 CONNECTOR 1
22 1434300 LOCK WASHER, TOOTH, M3 4
23 1211325 SCREW M3×25 2
24 8134060 PLATE, ON BOARD BATTERY CHARGER 1
25 8134061 CLEAR COVER 1
26 1221412 SCREW M4×12 4
27 8132010-US ON BOARD BATTERY CHARGER,KIT 1
28 8112030A BATTERY CHARGER POWER CORD, KIT 1
29 8132010A ON BOARD BATTERY CHARGER 1
30 1123406 LOCK NUT M4 4
31 8114005 CONNECTOR 1
32 1021840 HEX BOLT M8×40 2
33 1422821 LOCK WASHER M8 12
34 1421828 FLAT WASHER M8×
∮
28×3 2
35 1021630 HEX HEAD BOLT M6×30,SS 1
