Ice i24BT Operator's & Parts Manual

42
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SCRUB HEAD LIFT GROUP (i24BT)
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8137006 NON-SLIP MAT 1
2 8137100 BRACKET, SCRUB HEAD LIFT 1
3 8133151 BUMPER 1
4 1123810 LOCK NUT M8 5
5 1021830 HEX BOLT M8×30 2
6 1421824 FLAT WASHER M8×
∮
24×2 8
7 8117007 NYLON WASHER
∮
12.9×
∮
24×2.5 4
8 8115404 BEARING, JOURNAL 4
9 8115405 SLEEVE, P/M 2
10 1123115 LOCK NUT M12 1
11 1421124 FLAT WASHER M12
×∮
24
×
2.5 1
12 8126011 LEFT BRACKET 1
13 1422821 LOCK WASHER M8 3
14 1021820 HEX BOLT M8×20 3
15 1022845 HEX BOLT M8 ×45 1
16 8117004 ROLLER 1
17 8126010 RIGHT BRACKET 1
18 1021616 HEX BOLT M6 ×16 2
19 1422616 LOCK WASHER M6 2
20 1421612 FLAT WASHER M6×
∮
12×1.6 2
21 8137001 BRACKET, GUIDE 1
