Ice i24BT User Manual

59
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SCRUB HEAD LIFT GROUP (i20NB / i20NBT)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8137006 000101- NON-SLIP MAT 1
2 8137100 000101- BRACKET, SCRUB HEAD LIFT 1
3 8133151
000528- for i20NB
BUMPER 1
000449- for i20NBT
4 1123810 000101- LOCK NUT M8 5
5 1021830 000101- HEX BOLT M8×30 2
6 1421824 000101- FLAT WASHER M8×
∮
24×2 6
7 8117007 000101- NYLON WASHER
∮
12.9×
∮
24×2.5 4
8 8115404 000101- BEARING, JOURNAL 7
9 8115405 000101- SLEEVE, P/M 2
10 1021825 000101- HEX BOLT M8×25 4
11 1422821 000101- LOCK WASHER M8 4
12 1421816 000101- FLAT WASHER M8×
∮
16×1.6 4
13 8117002 000101- LEFT BRACKET 1
14 8117005 000101- SPACER(i20NB) 1
15 8117003 000101- RIGHT BRACKET 1
16 1022860 000101- HEX BOLT M8 ×60 1
17 8117008 000101- SPRING 1
18 8113109 000101- BEARING, THRUST 2
19 1022845 000101- HEX BOLT M8 ×45 1
20 8117004 000101- ROLLER 1
21 1421612 000101- FLAT WASHER M6×
∮
12×1.6 2
22 1422616 000101- LOCK WASHER M6 2
23 1021616 000101- HEX BOLT M6 ×16 2
24 8117009 000101- SPRING 1
25 8117001 000101- BRACKET, GUIDE 1
