Ice i24BT User Manual

61
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
ORBITAL HEAD LIFT GROUP (i20NBT-OB)
DIA
NO.
PART
NUMBER
SERIAL NUMBER DESCRIPTION
NO
REQ'D
1 8137006
000101-
NON-SLIP MAT 1
2 8137100
000101-
BRACKET, SCRUB HEAD LIFT 1
3 1021830
000101-
HEX HEAD BOLT M8×30 2
4 1421824
000101-
FLAT WASHER M8×
∮
24×2 8
5 8117007
000101-
NYLON WASHER
∮
12.9×
∮
24×2.5 4
6 1435013
000449-
WAVE WASHER 10
7 8115404
000101-
BEARING, JOURNAL 4
8 8115405
000101-
SLEEVE, P/M 2
9 1022845
000101-
HEX HEAD BOLT M8 ×45 1
10 8117004
000101-
ROLLER 1
11 1123810
000101-
LOCK NUT M8 3
12 1021616
000101-
HEX HEAD BOLT M6 ×16 2
13 1422616 000101- LOCK WASHER M6 2
14 1421612
000101-
FLAT WASHER M6×
∮
12×1.6 2
15 8117001 000101- BRACKET, GUIDE 1
