STEP 69:
Partly install two AA6281 Allen bolts and AA6212 washers on each side on the arch assembly.
There should be about 1/2 sticking out.
AA6212 1/4 X 3/4
black washer
STEP 70:
With a helper, raise the arch onto the brackets. The bolts you left hanging should “hook” on the
bracket. Make sure the washer is on the outside of the bracket.
Bolts hook on bracket
AA6281 1/4-20 X 1-1/2 BLACK
X’s 4
