Icegame DODGEBALL - Target PCB Dipswitch Settings

83
DB2033X Target PCB Dipswitch settings
Each board has two sets of dipswitches. These dipswitches determine the position and function. When installing any replacem
ent
boards, confirm the location of the board and set the dipswitches to match the location. Both RJ45 ports are identical. Either can be used for in or out communications.
