11
ENG
HOW TO ASSEMBLE THE
INDOOR CYCLE
2
PEOPLE
HAND TIGHT
11.
R
L
55 NM
WARNING!
Attach the pedal marked R on the right
crank and tighten by turning clockwise (standard
right-hand thread). Attach the pedal marked L on the
left crank and tighten by turning counter-clockwise
(left-hand thread). Please make sure that both pedals
are fastened with suffi cient force (55 NM), to ensure that
the bolt does not become loose during use.
The threads are provided with TufLok® at the factory
to prevent them from becoming loose during use.
If bolts are loosened after initial assembly, we
recommend using medium-strength LOCTITE® 243
when reassembling.
15 MM PEDAL
WRENCH
REMOVE 2 SCREWS WITH A PHILIPS SCREWDRIVER
AND DETACH THE PANEL WITH THE BATTERY.
CONNECT THE
WIRES MARKED
LIPO TOGETHER
AND REASSEMBLE
THE PANEL.
12.
PHILLIPS
SCREWDRIVER
