TECHNICAL DATA SHEET 02/2018 - ENG
ICMA S.p.a. via Garavaglia, 4 20012 Cuggiono (MI) – ITALIA
Tel. +39 02 97249134 / +39 02 97249135
www.icmaspa.it e-mail: sales@icmaspa.it
ART. S001-S002-S003-S004 SOLAR MODULE
SAFETY
Safety warnings
Read assembly and operating instructions carefully before starting up the system in order to prevent accidents and
damage to the system caused by improper use. Remember that your rights under the warranty will be forfeited if
you make any changes to the system or tamper with it during assembly and construction without authorisation. In
addition, you must follow the requirements of the regulations listed below:
DIN 4751
Water heating systems
DIN 4757
Solar heating systems
DIN 18380
Heating systems and hot water heating systems
DIN 18382
Electrical systems and pipes in buildings
DIN 12975
Thermal solar systems and components
OPERATING CONDITIONS
The limits on operating values specified must not be exceeded under any circumstances. Safe operation is guaranteed if you
comply with the general conditions and limits on operating valves described in this information sheet.
SAFETY STANDARDS FOR ASSEMBLY AND INSPECTION
Assembly and inspection operations must always be performed by qualified, authorised personnel familiar with the
instructions contained herein. Make sure the system is shut down before performing any work on it.
ELECTRICAL CONNECTIONS
Electrical connections must be made by qualified personnel. Connecting cables must be positioned in the cavity provided for
the purpose in the insulating shell 14 (Tab.1) so as to avoid contact with the body of the pump motor and with pipes.
Check that the power supply voltage is as specified on the plate before turning on the pump. All connections must be made as
required by law.
MAINTENANCE
Maintenance work must always be performed by qualified, authorised personnel familiar with the instructions contained
herein. Make sure the system is shut down before performing any work on it. When replacing the pump, turn the on/off valve,
return connection 4 (Tab.1) and flow control valve 6 (Tab.1) to the off position.
Warning! Depending on operating conditions in the pump and the system, the
surface temperature could be very high. Touching the pump directly comports
a risk of burning!
