Displaying the Maximum Temperatures recorded
Parameter ‘ TMAX U1 ’ allows to display the maximum
temperature recorded in the system for each probe TM-.
PRESS THE ‘  ‘ KEY
TO VIEW THE TEMPERATURE.

USING THE ‘  ‘ OR ‘  ‘ ARROWS IT IS POSSIBLE
TO SCROLL CYCLICALLY THROUGH THE RECORDED
TEMPERATURES:
TM1  TM2  TM3

PRESS THE ‘  ‘ KEY. THE DISPLAY SHOWS FLASHING
THE NUMBER OF THE PROBE.
PRESSING THE ‘ esc ’ KEY RETURNS TO SHOWING
THE USER PARAMETERS.

PRESSING ‘  ‘ RESETS THE TEMPERATURE
RECORDED TO THAT POINT;
PRESSING ‘ esc ’ RETURNS TO SHOWING THE
MEMORIZED TEMPERATURE.

PRESS THE ‘ esc ’ KEY TO QUIT THE MAXIMUM
TEMPERATURE DISPLAY MODE.
USING THE ‘  ‘ OR ‘  ‘ ARROWS IT IS POSSIBLE TO
ENABLE OR DISABLE THE ANTIFROST:
0: DISABLED
1: ENABLED (THE DISPLAY SHOWS )

PRESS THE ‘  ‘ KEY TO CONFIRM THE
PROGRAMMING OR PRESS THE ‘ esc ’ KEY TO QUIT
USER PARAMETERS.
Antifrost Activation
The ‘ AFR U2 ’ parameter (anti-frost) enables or disables the
antifrost function. The management of the antifrost data is
performed through the user parameters.

PRESS THE ‘  ‘ KEY;
THE DISPLAY SHOWS ‘AFR’ FLASHING.
