Mar. 2009
1
SECTION 6
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[ANT UNIT][VERSION LIST]
[CONNECT UNIT]
[MAIN UNIT] (For F24/S F25/S F26/S F4018)
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L601 6200013010 S.COI 0.30-0.9-5TL 10.3N <COMO> B 7.2/12.5
C601 4030017600 S.CER ECJ0EC1H080C B 5.8/15.3
C501 4030017460 S.CER ECJ0EB1E102K T 8.3/5.3
C502 4030016930 S.CER ECJ0EB1A104K T 9.3/5.3
J501 6910016390 CON IMSA-9230B-1-02Z145-PT1
IC1 1110003201 S.IC TA31136FNG(EL) B 51.8/19
IC2 1130008561 S.IC TC75S51F(TE85L,F) T 68.9/21
IC4 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 38.3/35.7
IC5 1110005340 S.IC NJM12902V-TE1-#ZZZB T 29.7/11.6
IC6 1110005320 S.IC NJM13403V-TE1-#ZZZB T 15.9/34.6
IC7 1110005330 S.IC NJM12904V-TE1-#ZZZB T 29.2/34.6
IC8 1190000350 S.IC M62363FP-650C T 40.3/15.2
IC9 1110005350 S.IC NJM2870F05-TE1-#FZZB B 84.2/14.2
IC10 1130011770 S.IC CD4066BPWR T 22.9/34.6
IC12 1110001811 S.IC TA7368FG(5,ER) T 89.3/13.2
IC13 1140012721 S.IC HD6433687C73FPV(FX-2775A-1) T 12.5/14.3
IC14 1110006260 S.IC BD5242G-TR T 6.6/5.9
IC15 1130011540 S.IC BR24L16FV-WE2 B 16/11.6
Q1 1560000841 S.FET 2SK1829(TE85R,F) T 75/39.6
Q2 1580000731 S.FET 3SK293(TE85L,F) B 76.8/37.9
Q3 1580000800 S.FET 3SK324UG-TL-E B 66.2/37.9
Q4 1530002601 S.TRA 2SC4215-O(TE85R,F) B 51.4/23.1
Q5 1530000371 S.TRA 2SC3356-T1B S (R25) T 74.3/33.5
Q6 1590003231 S.TRA UNR9113G0L T 72.5/19.1
Q7 1560001232 S.FET RD07MVS2-T112 T 82.6/27
Q8 1560001241 S.FET RD01MUS1-T113 T 76.1/27.5
Q9 1530003311 S.TRA 2SC5107-O(TE85R,F) T 67/30.3
Q10 1530003311 S.TRA 2SC5107-O(TE85R,F) T 59.4/36.3
Q11 1530003311 S.TRA 2SC5107-O(TE85R,F) B 56.3/37
Q12 1530003311 S.TRA 2SC5107-O(TE85R,F) T 59/31.5
Q13 1530002920 S.TRA 2SC4226-T1 R25 T 54.9/30.7
Q14 1530002920 S.TRA 2SC4226-T1 R25 T 54.2/37.1
Q15 1590001400 S.TRA XP1214(TX) B 56.5/32.6
Q16 1590003291 S.TRA UNR9213G0L B 59.1/32.6
Q17 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 55.5/44.1
Q18 1560000541 S.FET 2SK880-Y(T5RICOM,F) B 51.5/40.4
Q19 1530002851 S.TRA 2SC4116-BL(TE85R,F) T 43.3/29.9
Q21 1510000920 S.TRA 2SA1577 T106 Q T 71.9/16.4
Q22 1510000920 S.TRA 2SA1577 T106 Q T 24.9/25.9
Q23 1520000460 S.TRA 2SB1132 T100 R T 81/15.2
Q24 1590001190 S.TRA XP6501-(TX).AB T 76.3/15.1
Q25 1590003231 S.TRA UNR9113G0L T 75.7/11.7
Q26 1590003291 S.TRA UNR9213G0L T 49.7/18.4
Q27 1590003291 S.TRA UNR9213G0L T 24.8/16.7
Q28 1590003431 S.TRA UNR911HG0L B 63.1/10.6
Q29 1590003271 S.TRA UNR9210G0L B 35.7/9.2
Q30 1510001080 S.TRA 2SA2048 TLR T 91.9/8.6
Q31 1590001190 S.TRA XP6501-(TX).AB T 91.4/5.2
Q32 1590003020 S.TRA XP4216-(TX) T 16.5/23.1
Q33 1590003231 S.TRA UNR9113G0L T 19.9/22.5
Q34 1560001360 S.FET 2SK3019 TL T 10.7/30.1
Q35 1560001360 S.FET 2SK3019 TL T 9.1/26.6
D1 1750001080 S.DIO RB886G T2R B 90.2/38.7
D2 1750000581 S.DIO 1SV307(TPH3,F) B 91.5/31.1
D3 1750000711 S.VAR HVC350BTRF-E B 87.5/33.5
D4 1750000711 S.VAR HVC350BTRF-E B 87.5/34.8
D5 1790001261 S.DIO MA2S077G0L B 87.4/36.7
D6 1790001241 S.DIO MA2S7280GL B 85/39.9
D7 1750000711 S.VAR HVC350BTRF-E B 81.8/33.5
D8 1750000711 S.VAR HVC350BTRF-E B 81.8/34.8
D9 1750000711 S.VAR HVC350BTRF-E B 73.6/35.9
D10 1750000711 S.VAR HVC350BTRF-E B 72.2/35.9
D14 1790001261 S.DIO MA2S077G0L T 65.8/35.3
D15 1790001261 S.DIO MA2S077G0L T 65.8/36.7
D16 1750000711 S.VAR HVC350BTRF-E T 52.6/38.9
D17 1750000711 S.VAR HVC350BTRF-E T 49.4/28.3
D18 1720000570 S.VAR MA368(TX) B 49.6/26.9
D21 1750000711 S.VAR HVC350BTRF-E T 50.5/33.7
D22 1750000711 S.VAR HVC350BTRF-E T 50.5/35.2
D24 1790001251 S.DIO MA2S1110GL T 41.5/39.2
D25 1790001251 S.DIO MA2S1110GL T 70.5/40.4
D26 1790001790 S.DIO RB876W TL B 35.7/7.1
D27 1750000520 S.DIO DAN222TL B 21.3/6
D28 1790001261 S.DIO MA2S077G0L B 8.5/11.2
S.=Surface mount
MODEL VERSION
SYMBOL
IC-F24
USA-02 [A]
GEN-03 [B]
BEA-02 [D]
GEN-02 [E]
GEN-03 [F]
USA-04 [G]
USA-05
[T]
IC-F25
EUR-02 [C]
IC-F26
RUS-02 [H]
RUS-05 [I]
CHN-02 [U]
IC-F24S
OSA-02 [K]
USA-03
[L]
BEA-02 [N]
GEN-02
[O]
GEN-03 [P]
USA-04
[Q]
IC-F25S
EUR-02 [M]
IC-F26S
RUS-02 [R]
RUS-05
[S]
IC-F26-L
EXP-01 [J]
CHN-01 [V]
IC-F4018
CHN-01 [W]
IC-F4018-L
CHN-01 [X]
