BC-160 DESKTOP CHARGER + BC-145 AC ADAPTER
Charges the BP-231 in 2 hours (approx.).
BC-119N DESKTOP CHARGER + AD-106 CHARGER ADAPTER
+ BC-145 AC ADAPTER : Charges the BP-231 in 2 hours (approx.).
CP-17L CIGARETTE LIGHTER CABLE, OPC-515L DC POWER CABLE
For use with the BC-160 or BC-119N. (12–16V DC required).
BC-121N MULTI-CHARGER + AD-106 CHARGER ADAPTER
+ BC-157 AC ADAPTER
(Six AD-106s are required)
Charges up to 6 battery packs in 2 hours (approx.) when BP-231 is attached.
OPC-656 DC POWER CABLE : For use with the BC-121N.
(12–20V DC required)
.
UT-108 : Provides DTMF, Selective call and ANI capabilities.
UT-109 : Up to 32 scrambling codes are available. Version 01 is required.
UT-110 : Up to 1020 scrambling codes are available. Version 01 is required.
UT-113 : Automatically sends an emergency signal when the transceiver is left in a hori-
zontal position for a preset time.
MB-93 : Swivel type. A fast and easy way to
remove the transceiver from your
belt.
MB-94 : Alligator type. Same as supplied.
MB-96N: Swivel type belt hanger. Swivel
joint of the MB-93 included.
MB-96F : Fixed type belt hanger. For use
with MB-94.
OPTIONS
SP-13 : EARPHONE
Provides clear audio in noisy
environments.
STUBBY ANTENNAS
• FA-SC56VS : 146–162MHz
• FA-SC57VS : 160–174MHz
• FA-SC73US : 450–490MHz
ANTENNAS
• FA-SC25V : 136–150MHz
• FA-SC55V : 146–174MHz
• FA-SC25U : 400–430MHz
• FA-SC57U : 430–470MHz
Some options may not be available in some countries. Please ask your dealer for details.
Lithium-Ion battery standard
The IC-F15/S series comes with the BP-
231
Li-Ion battery pack as standard. Li-Ion
batteries have virtually no memory issues
and allows you flexible charging. In addi-
tion, the optional BP-232 provides a high
capacity 2000mAh for longer operating
time.
Optional board
The IC-F15/S series has an expansion
socket for adding an optional board. Voice
scrambler, man down and DTMF decoder
features are available, depending on the
installed board.
Most popular signalings built-in
Use the built-in 2-Tone, 5-Tone, CTCSS
and DTCS capabilities as standard to set
up your own talk groups and quiet stand-
by when others are talking.
Multiple 2-Tone, Multiple 5-Tone
Up to 10 2-Tone/8 5-Tone codes can be
decoded on a channel. When a matched
tone is received, the following items are
programmable for each code.
• Beep sound • Answer back • Stun
• LED blink • Scan
Other features
• LED low battery alert
• TOT function and lock out penalty timer
• 2 step power saver
• Normal and priority scan
• 500mW loud and clear audio
• Optional VOX headset for hands free
operation
• PC programming capability
• Embedded ESN
(Electronic serial number)
’s new direction in PMR radio de-
yone but a powerful and reliable
very durable construction is re-
he dual rail guide design securely
dio. Wide range frequency cover-
nd clear audio, built-in signalings
bined with Icom grade electrical
s will easily exceed your expecta-
▲ BP-231 ▲ BP-240
Battery Type and
Operating time
* Output
power
packs capacity (VHF/UHF) (VHF/UHF)
BP-230
Li-Ion
6/6 hours 5W/4W
7.4V/ 800mAh
BP-231
Li-Ion
9/8 hours 5W/4W
7.4V/1150mAh
BP-232
Li-Ion
16/15 hours 5W/4W
7.4V/2000mAh
BP-240
AAA (LR03)
–1W
batteries × 6
* Operating time is approximate time (at 20˚C). Tx: Rx: standby=5:5:90.
Power save on.
▲ BC-160
RAPID CHARGER
▲ BC-145
BELT CLIPS
▲ MB-93 ▲ MB-94▲ OPC-515L▲ CP-17L
▲ BC-121N+AD-106 (6 pcs.)
MULTI-CHARGER LEATHER BELT HANGERS
▲ MB-96F▲ MB-96N▲ OPC-656
UT-109 VOICE
SCRAMBLER UNIT
UT-108
DTMF DECODER
UT-113 MAN
DOWN UNIT
INTERNAL UNITS
UT-110 VOICE
SCRAMBLER UNIT
▲ BP-230
BATTERY PACKS AND CASE
▲ BP-232
▲ BC-157
HS-94: Earhook headset with flexible boom microphone.
HS-95: Behind-the-head headset with flexible boom microphone.
HS-97:
Throat microphone fits around your neck and picks up speech vibration.
VS-1L: PTT/VOX unit. Required when using these headsets with the transceiver.
▲ HS-95
▲ HS-97
HEADSETS and PTT/VOX UNIT
▲ HS-94
▲ VS-1L
HM-158L : Compact and durable body with
screw-type connector.
HM-153L : Durable earphone-microphone
with revolving clip.
SPEAKER-MICROPHONES
▲ HM-158L ▲ HM-153L
