Icom IC-F1610 Service Manual

Q30 1590002290 S.TRANSISTOR FMS2A T148
Q31 1590002300 S.TRANSISTOR FMW2 T148
Q32 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q33 1510000510 S.TRANSISTOR 2SA1576A T106R
Q35 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q36 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q37 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q38 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q39 1590000850 S.TRANSISTOR DTC114YUA T106
Q40 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q41 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q42 1520000560 S.TRANSISTOR 2SB1123T-TD
Q43 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q44 1560000810 S.FET 2SK1069-4-TL
Q45 1590000430 S.TRANSISTOR DTC144EUA T106
Q47 1590000430 S.TRANSISTOR DTC144EUA T106
Q48 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q50 1590001330 S.TRANSISTOR DTA114EUA T106
Q51 1590000680 S.TRANSISTOR DTC114EUA T106
Q52 1560000810 S.FET 2SK1069-4-TL
Q55 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q56 1590000720 S.TRANSISTOR DTA144EUA T106
Q61 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q62 1590000430 S.TRANSISTOR DTC144EUA T106
Q64 1590000430 S.TRANSISTOR DTC144EUA T106
Q65 1560000840 S.FET 2SK1829 (TE85R)
Q501 1590000430 S.TRANSISTOR DTC144EUA T106
Q502 1590000720 S.TRANSISTOR DTA144EUA T106
Q503 1590001650 S.TRANSISTOR XP4601 (TX)
Q504 1560000810 S.FET 2SK1069-4-TL
Q505 1590000430 S.TRANSISTOR DTC144EUA T106
Q506 1560000810 S.FET 2SK1069-4-TL
Q507 1590000430 S.TRANSISTOR DTC144EUA T106
Q508 1560000840 S.FET 2SK1829 (TE85R)
Q509 1590000430 S.TRANSISTOR DTC144EUA T106
Q510 1590000430 S.TRANSISTOR DTC144EUA T106
Q511 1590000720 S.TRANSISTOR DTA144EUA T106
Q512 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q513 1590000720 S.TRANSISTOR DTA144EUA T106
Q514 1590000720 S.TRANSISTOR DTA144EUA T106
Q515 1590000720 S.TRANSISTOR DTA144EUA T106
Q516 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q517 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1790001210 S.DIODE 1SS375-TL
D3 1790001210 S.DIODE 1SS375-TL
D4 1750000510 S.DIODE UM9401F
D5 1710000730 S.DIODE MI809-T11
D6 1710000730 S.DIODE MI809-T11
D7 1720000270 S.VARICAP 1SV217 (TPH2)
D9 1720000270 S.VARICAP 1SV217 (TPH2)
D10 1720000270 S.VARICAP 1SV217 (TPH2)
D11 1720000270 S.VARICAP 1SV217 (TPH2)
D15 1790000700 DIODE DSA3A1
D16 1750000370 S.DIODE DA221 TL
D17 1790000620 S.DIODE MA77 (TX)
D18 1790000620 S.DIODE MA77 (TX)
D19 1720000270 S.VARICAP 1SV217 (TPH2)
D20 1720000270 S.VARICAP 1SV217 (TPH2)
D21 1720000270 S.VARICAP 1SV217 (TPH2)
D22 1720000270 S.VARICAP 1SV217 (TPH2)
D23 1720000260 S.VARICAP 1SV214 (TPH2)
D27 1750000130 S.DIODE DA204U T107
D28 1750000220 S.DIODE DA113W T107
D29 1750000130 S.DIODE DA204U T107
D30 1750000550 S.DIODE 1SS355 TE-17
D31 1750000550 S.DIODE 1SS355 TE-17
D32 1750000130 S.DIODE DA204U T107
D33 1730002420 S.ZENER MA8160 (TX)
D36 1750000550 S.DIODE 1SS355 TE-17
D37 1750000550 S.DIODE 1SS355 TE-17
D38 1750000550 S.DIODE 1SS355 TE-17
D40 1720000270 S.VARICAP 1SV217 (TPH2)
D41 1720000270 S.VARICAP 1SV217 (TPH2)
D42 1720000270 S.VARICAP 1SV217 (TPH2)
D43 1720000270 S.VARICAP 1SV217 (TPH2)
D44 1720000360 S.DIODE HSU88TRF
D45 1750000550 S.DIODE 1SS355 TE-17
D46 1720000260 S.VARICAP 1SV214 (TPH2)
D50 1750000550 S.DIODE 1SS355 TE-17
D51 1750000550 S.DIODE 1SS355 TE-17
[MAIN UNIT][FRONT UNIT]
S.=Surface mount
DS11 5040002030 S.LED CL-170Y-CD-T
DS13 5040002030 S.LED CL-170Y-CD-T
DS14 5040002030 S.LED CL-170Y-CD-T
DS15 5040002030 S.LED CL-170Y-CD-T
DS16 5040002030 S.LED CL-170Y-CD-T
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W4 7030000010 S.JUMPER MCR10EZHJ JPW (000)
EP1 0910050602 PCB B 5205B
EP2 8930048320 LCD CONTACT SRCN-2140-SP-N-W
IC1 1110003571 S.IC MC3372SVMEL
IC2 1130007370 S.IC TA75S558F (TE85L)
IC3 1130007090 S.IC TA75W558FU (TE12L)
IC5 1190000350 S.IC M62363FP-650C
IC7 1110003300 S.IC M5282FP 70CD
IC8 1110003090 IC LA4425A
IC9 1130007090 S.IC TA75W558FU (TE12L)
IC10 1110003800 S.IC NJM2904V-TE1
IC11 1150001040 IC SC-1188
IC12 1130007970 S.IC MC145190FR2
IC13 1130007300 S.IC TC4W66FU (TE12L)
IC16 1180001250 S.IC TA7808F (TE16L)
IC17 1180000970 S.IC AN78L05M-(E1)
IC18 1130007110 S.IC TC7W04FU (TE12L)
IC19 1110003500 S.IC S-80742SL-A6-T1
IC20 1140007640 S.IC HD64F3437F16
IC21 1130006920 S.IC TA75W01FU (TE12L)
IC22 1110003410 S.IC µPC5023GR-043-GJG-T2
IC25 1130007300 S.IC TC4W66FU (TE12L)
IC26 1130007110 S.IC TC7W04FU (TE12L)
IC27 1130009020 S.IC X25650S8I-2.5T6
IC29 1110002750 S.IC TA75S01F (TE85R)
IC501 1130004230 S.IC LC7366NM
IC502 1130007020 S.IC TC7S66FU (TE85R)
IC503 1110002750 S.IC TA75S01F (TE85R)
IC504 1130006220 S.IC TC4W53FU (TE12L)
IC505 1130008090 S.IC BU4066BCFV-E1
IC506 1180001080 S.IC S-81250PG-PD-T1
Q1 1580000590 S.FET 3SK166A-0-T7
Q2 1580000590 S.FET 3SK166A-0-T7
Q3 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q6 1590000680 S.TRANSISTOR DTC114EUA T106
Q7 1590000990 S.TRANSISTOR DTC363EK T147
Q8 1590000680 S.TRANSISTOR DTC114EUA T106
Q9 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q10 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q11 1550000020 S.FET 2SJ377 (TE16R)
Q12 1550000020 S.FET 2SJ377 (TE16R)
Q14 1590000430 S.TRANSISTOR DTC144EUA T106
Q15 1530003291 S.TRANSISTOR 2SC4703-T1 SE
Q16 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q17 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q18 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q19 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q20 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q21 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q22 1590000850 S.TRANSISTOR DTC114YUA T106
Q23 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q24 1590000850 S.TRANSISTOR DTC114YUA T106
Q25 1590000430 S.TRANSISTOR DTC144EUA T106
Q26 1590001330 S.TRANSISTOR DTA114EUA T106
Q27 1590000720 S.TRANSISTOR DTA144EUA T106
Q28 1590000720 S.TRANSISTOR DTA144EUA T106
Q29 1560000810 S.FET 2SK1069-4-TL
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
