Icom IC-F1610 Service Manual

S.=Surface mount
C517 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C518 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C519 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C520 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C521 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C522 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C524 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C525 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C526 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C527 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C528 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C529 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C530 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C531 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C532 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C533 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C534 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C535 4030004760 S.CERAMIC C2012 JF 1E 104Z-T-A
C536 4030004760 S.CERAMIC C2012 JF 1E 104Z-T-A
C537 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C538 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C539 4550003260 S.TANTALUM TEMSVA 1V 684M-8L
C540 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C541 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C542 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C543 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C544 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C545 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C546 4030009580 S.CERAMIC C1608 JB 1H 681K-T-A
C547 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C549 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C550 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C551 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C552 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C553 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C554 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C555 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C556 4550000460 S.TANTALUM TESVA 1C 105M1-8L
C557 4510006090 S.ELECTROLYTIC ECEV0GA470SR
C558 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C559 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C560 4550002890 S.TANTALUM TESVA 1A 225M1-8L
C561 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C562 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C563 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C564 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C565 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
J2 6450000140 CONNECTOR HSJ0807-01-010
J4 6510019250 S.CONNECTOR B11B-ZR-SM3-TF
J5 6510018040 CONNECTOR 52330-1217
J6 6510018430 S.CONNECTOR AXN330C038P
J7 6510019270 S.CONNECTOR 52365-0691
J501 6510021300 S.CONNECTOR 52365-1091
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 8900004540 CABLE OPC-453
W6 7120000470 JUMPER ERDS2T0
W7 7030003860 S.JUMPER ERJ3GE JPW V
W12 7030003860 S.JUMPER ERJ3GE JPW V
W25 7030003860 S.JUMPER ERJ3GE JPW V [EUR-8]
W26 7030003860 S.JUMPER ERJ3GE JPW V [EUR-11]
W505 7030003860 S.JUMPER ERJ3GE JPW V
W506 7030003860 S.JUMPER ERJ3GE JPW V
W507 7030003860 S.JUMPER ERJ3GE JPW V
W508 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910050592 PCB B 5203B
EP2 6910010220 BEAD HF70BB3.5X5X1.3
EP3 6910010280 BEAD HF70BB9.5X10.4X4.9
EP1 0880000150 UNIT BOARD UT-96 [EUR-11] only
6 - 8
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[TONE UNIT]
