Icom IC-F1710 Service Manual

[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C26 4030017420 S.CER ECJ0EC1H470J T 73.4/8.7
C27 4030017420 S.CER ECJ0EC1H470J T 68.5/14.9
C28 4030017420 S.CER ECJ0EC1H470J T 70.3/14.9
C29 4030017420 S.CER ECJ0EC1H470J B 77.5/32.6
C30 4030017510 S.CER ECJ0EC1H680J B 82.1/36.4
C31 4030017330 S.CER ECJ0EF1C104Z T 74.3/61.9
C32 4510004630 S.ELE ECEV1CA100SR T 80.6/62.2
C33 4030017420 S.CER ECJ0EC1H470J T 75.4/68.2
C34 4030017620 S.CER ECJ0EC1H100C B 41.2/29.6
C37 4030017710 S.CER ECJ0EC1H181J T 53/25.4
C38 4030017400 S.CER ECJ0EC1H220J B 44.3/24.4
C39 4030017910 S.CER ECJ0EB1H152K B 52.1/28.5
C41 4030017760 S.CER ECJ0EB1H222K B 66.7/14
C42 4030017460 S.CER ECJ0EB1E102K B 66.7/17.6
C43 4030017420 S.CER ECJ0EC1H470J T 137/12.8
C44 4030017460 S.CER ECJ0EB1E102K B 141.4/6.5
C45 4030017460 S.CER ECJ0EB1E102K T 130.6/6
C46 4030017420 S.CER ECJ0EC1H470J T 74.6/16.3
C47 4030017420 S.CER ECJ0EC1H470J T 72.3/14.9
C48 4030017460 S.CER ECJ0EB1E102K B 74.9/69.2
C49 4030017460 S.CER ECJ0EB1E102K B 70.5/60.2
C50 4030017420 S.CER ECJ0EC1H470J B 72.3/60.2
C51 4030016790 S.CER ECJ0EB1C103K B 40.2/27.2
C52 4030016930 S.CER ECJ0EB1A104K B 41.2/27.2
C53 4030016790 S.CER ECJ0EB1C103K B 37/27.2
C54 4030017500 S.CER ECJ0EC1H560J B 35.8/29
C55 4030017570 S.CER ECJ0EC1H040B B 34.8/29
C56 4030017590 S.CER ECJ0EC1H070C B 34.8/27.1
C60 4510004630 S.ELE ECEV1CA100SR T 44.9/18.6
C61 4030017760 S.CER ECJ0EB1H222K B 56.4/18.2
C62 4030017460 S.CER ECJ0EB1E102K T 46.1/21.5
C63 4030017400 S.CER ECJ0EC1H220J B 47.9/24.4
C64 4030016930 S.CER ECJ0EB1A104K T 49.3/21.7
C65 4030016930 S.CER ECJ0EB1A104K B 54.3/28.5
C66 4030016930 S.CER ECJ0EB1A104K B 63.1/8.3
C67 4030016930 S.CER ECJ0EB1A104K B 8.8/11.9
C68 4030017640 S.CER ECJ0EC1H150J B 6.1/17.2
C69 4030017390 S.CER ECJ0EC1H180J B 6.1/21
C70 4030016930 S.CER ECJ0EB1A104K B 85.7/39.7
C71 4030017620 S.CER ECJ0EC1H100C B 85.7/45.7
C72 4030017460 S.CER ECJ0EB1E102K B 85.7/41.7
C73 4030017430 S.CER ECJ0EC1H101J T 80.6/46.3
C75 4030017460 S.CER ECJ0EB1E102K B 72.4/57
C76 4030016930 S.CER ECJ0EB1A104K B 62.9/32.9
C77 4030016930 S.CER ECJ0EB1A104K T 56.2/25.9
C78 4030018080 S.CER ECJ0EB1H182K T 54.4/23.9
C79 4030016930 S.CER ECJ0EB1A104K B 75.1/26.4
C80 4030017460 S.CER ECJ0EB1E102K B 75.1/25.4
C81 4030016930 S.CER ECJ0EB1A104K B 12/11.9
C82 4030016930 S.CER ECJ0EB1A104K B 85.7/43.7
C83 4030017460 S.CER ECJ0EB1E102K B 81.2/51.1
C84 4030017460 S.CER ECJ0EB1E102K B 80.2/51.1
C85 4030017620 S.CER ECJ0EC1H100C B 72.4/59
C87 4030017360 S.CER ECJ0EC1H030B B 32.4/27.1
C88 4030016930 S.CER ECJ0EB1A104K T 28.7/14.1
C89 4030016930 S.CER ECJ0EB1A104K T 26.7/14.1
C90 4030016930 S.CER ECJ0EB1A104K B 62.7/27.3
C91 4030018860 S.CER ECJ0EB0J105K T 109.6/47.5
C93 4030016930 S.CER ECJ0EB1A104K B 69/36.2
C94 4030016930 S.CER ECJ0EB1A104K T 114/46.5
C95 4030016930 S.CER ECJ0EB1A104K B 62.1/8.3
C96 4030016930 S.CER ECJ0EB1A104K B 69.9/21.7
C98 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 85.5/24.1
C100 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 83.6/24.1
C104 4030017590 S.CER ECJ0EC1H070C B 70.5/57
C107 4030016930 S.CER ECJ0EB1A104K B 29.1/24.1
C108 4030016930 S.CER ECJ0EB1A104K T 25.9/19.1
C109 4030016930 S.CER ECJ0EB1A104K T 111.2/65.8
C110 4030016930 S.CER ECJ0EB1A104K B 137.2/5.3
C111 4030016930 S.CER ECJ0EB1A104K B 61.4/25.3
C112 4030016930 S.CER ECJ0EB1A104K B 68.3/21.7
C113 4030016930 S.CER ECJ0EB1A104K T 119.7/49.5
C114 4030018860 S.CER ECJ0EB0J105K T 115.7/46.5
C115 4030017420 S.CER ECJ0EC1H470J T 117.7/49.5
C119 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 85/17.9
C120 4030017460 S.CER ECJ0EB1E102K T 76.9/39.8
C121 4030018860 S.CER ECJ0EB0J105K T 76.9/36.8
C122 4030017730 S.CER ECJ0EB1E471K T 69.4/47.3
C123 4030017590 S.CER ECJ0EC1H070C B 68.7/58
C124 4550003220 S.TAN TEESVA 1E 105M8L B 75.7/51
C125 4030017420 S.CER ECJ0EC1H470J B 74.8/54
C126 4030017380 S.CER ECJ0EC1H050B B 68/59
C127 4030018860 S.CER ECJ0EB0J105K T 76.9/34.7
C128 4030017460 S.CER ECJ0EB1E102K T 76.9/32.6
C129 4030017460 S.CER ECJ0EB1E102K T 28.8/25.3
C130 4030016930 S.CER ECJ0EB1A104K B 26.6/23.7
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C131 4030017720 S.CER ECJ0EB1H331K B 24/28.3
C132 4030018140 S.CER ECJ0EB1H391K B 22.3/27.3
C133 4030017460 S.CER ECJ0EB1E102K B 20.6/28.3
C134 4030017460 S.CER ECJ0EB1E102K B 24/33
C135 4030018910 S.CER C1608 JB 0J 475K-T T 107.3/53
C136 4030016930 S.CER ECJ0EB1A104K T 110/52.9
C137 4030017770 S.CER ECJ0EB1E332K T 119.7/51.2
C138 4030017420 S.CER ECJ0EC1H470J T 110/54.6
C139 4030017420 S.CER ECJ0EC1H470J T 117.7/51.2
C140 4550006250 S.TAN TEESVA 1A 106M8L
[F2721D], [F2821D] only T 81/15.3
C141 4030017450 S.CER ECJ0EB1E271K
[F2721D], [F2821D] only T 85.9/13.7
C142 4030017730 S.CER ECJ0EB1E471K
[F2721D], [F2821D] only T 87.7/13.7
C143 4030017420 S.CER ECJ0EC1H470J
[F2721D], [F2821D] only T 89.5/13.7
C144 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 80.5/13.7
C145 4030017680 S.CER ECJ0EC1H820J
[F2721D], [F2821D] only T 89.5/14.7
C146 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only B 119.9/40.3
C147 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only B 114.5/45
C148 4030017590 S.CER ECJ0EC1H070C
[F2721D], [F2821D] only B 90.9/19
C149 4550007080 S.TAN TEESVA 1C 106M8R
[F2721D], [F2821D] only B 87.5/24.6
C150 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 87.9/21.5
C151 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 87/15.9
C152 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 87/16.9
C153 4030017420 S.CER ECJ0EC1H470J B 68.9/55.6
C155 4030016790 S.CER ECJ0EB1C103K B 68.9/54.6
C156 4550007080 S.TAN TEESVA 1C 106M8R B 71.8/50.4
C161 4030016930 S.CER ECJ0EB1A104K B 62.4/46.9
C162 4550006250 S.TAN TEESVA 1A 106M8L T 24.7/27.6
C163 4030017430 S.CER ECJ0EC1H101J B 30.6/32.9
C164 4030017430 S.CER ECJ0EC1H101J T 25.7/31.3
C165 4030017460 S.CER ECJ0EB1E102K B 36.2/35.7
C166 4030017420 S.CER ECJ0EC1H470J B 27.3/33.9
C167 4030017460 S.CER ECJ0EB1E102K B 28.4/33.9
C168 4030017460 S.CER ECJ0EB1E102K B 54.8/8.6
C170 4030017740 S.CER ECJ0EB1E821K T 113.6/56.4
C171 4030017730 S.CER ECJ0EB1E471K T 117.2/56.4
C172 4030016930 S.CER ECJ0EB1A104K T 111.6/56.4
C173 4030017420 S.CER ECJ0EC1H470J T 117.7/52.9
C174 4030017510 S.CER ECJ0EC1H680J T 115.2/56.4
C175 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 85.6/20.2
C176 4030017420 S.CER ECJ0EC1H470J
[F2721D], [F2821D] only B 89.9/11.4
C177 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 90.9/11.4
C178 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only T 102.4/38.5
C179 4030017760 S.CER ECJ0EB1H222K
[F2721D], [F2821D] only B 92.9/11.4
C180 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only T 91.3/19.1
C181 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only B 102.6/40.4
C182 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only B 124.5/26.3
C183 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 92.9/19
C184 4550007080 S.TAN TEESVA 1C 106M8R
[F2721D], [F2821D] only B 97.3/16.8
C185 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 100.8/16.3
C186 4030016790 S.CER ECJ0EB1C103K
[F2721D], [F2821D] only B 116.5/16.7
C187 4030017760 S.CER ECJ0EB1H222K
[F2721D], [F2821D] only B 91.9/20.8
C188 4030017600 S.CER ECJ0EC1H080C T 46.2/52.4
C190 4030017380 S.CER ECJ0EC1H050B [L] T 46.2/51.4
4030017590 S.CER ECJ0EC1H070C [H] T 46.2/51.4
C191 4030017380 S.CER ECJ0EC1H050B [L] T 43.6/53.6
4030017590 S.CER ECJ0EC1H070C [H] T 43.6/53.6
C192 4030017580 S.CER ECJ0EC1H060C [H] T 46.2/48
4030017590 S.CER ECJ0EC1H070C [L] T 46.2/48
C193 4030016930 S.CER ECJ0EB1A104K B 41.8/48.2
C194 4030017530 S.CER ECJ0EC1H0R5B T 67.6/49.3
C196 4030017380 S.CER ECJ0EC1H050B T 46.2/49
C197 4030017380 S.CER ECJ0EC1H050B [H] T 43.6/46.8
4030017570 S.CER ECJ0EC1H040B [L] T 43.6/46.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 8
