S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT-A UNIT] (for IC-F1700 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT-B UNIT] (for IC-F1800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
DS7 5040002310 S.LED SML-311YTT86 T 20.9/6.5
DS8 5040002310 S.LED SML-311YTT86 T 93.4/6.5
DS9 5040002310 S.LED SML-311YTT86 T 78.9/6.5
DS11 5040002310 S.LED SML-311YTT86 T 82.1/27
DS12 5040002310 S.LED SML-311YTT86 T 72.1/27
DS13 5040002310 S.LED SML-311YTT86 T 62.1/27
DS14 5040002310 S.LED SML-311YTT86 T 52.1/27
DS15 5040002310 S.LED SML-311YTT86 T 42.1/27
DS16 5040002310 S.LED SML-311YTT86 T 32.1/27
DS17 5040002930 S.LED SML-512MW T86 T 105.6/14
DS18 5040002990 S.LED SML-512UWT86 T 97.6/14
DS26 5040002310 S.LED SML-311YTT86 T 64.4/6.5
S9 2250000510 ECR RH70N1037E20-13.5F-2781
SP1 2510001290 SP C062SB504-11
W1 8900013690 CBL OPC-1425 (N=12,L=92)
W2 8900013700 CBL OPC-1426
EP1 8930065150 LCT SRCN-2781-SP-N-W
EP2 0910058062 PCB B 6155B
R29 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 28.5/17.3
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 17.6/15.9
R31 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 10.7/20.1
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 12/20.6
R33 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
)
R34 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 131.6/30.4
R35 7210003050 VAR EVU-F2KFK3 B14 (10KB)
R36 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 99.2/29.1
R37 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 99.2/27.8
R38 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 89.6/10.6
R39 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 91.3/13.3
R40 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 56.2/8.5
R41 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 58.7/8.5
R42 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 61.3/8.5
R43 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 99.5/15
R44 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 107.6/11.9
R48 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 77.6/28.8
R49 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 78.5/29
R50 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 79.4/29.3
R51 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 80.3/29.6
R52 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 81.2/29.3
R55 7510001470 S.TMR NTCG20 4AG 473JT B 85/24.7
R56 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 83.6/26.1
R57 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 61.8/24.4
R58 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
Ω
) B 59.6/27.3
R59 7310002820 S.TRI RV-158 (RH03A3AS5) 474 B 58.6/24.8
R60 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 8.1/9.2
R61 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 5.9/3.6
R62 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 27.1/8
R63 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 35.1/6
R64 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 29.7/12.4
R65 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 33.1/10.5
R66 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 34.7/10.5
R67 7030009280 S.RES ERJ2GE B 28.4/10.2
R68 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 29.7/9.2
R70 7410001130 S.ARY EXB28V102JX B 66.5/17.7
R71 7410001130 S.ARY EXB28V102JX B 55.1/16.7
R72 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 86.5/27
R73 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 21/26.7
R74 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 12.4/9.2
R75 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 53.8/22.8
R76 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 75.8/29.5
R77 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 5.9/5.2
R80 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 147.9/30.4
R81 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 67.1/8.4
R82 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 65.8/8.4
R83 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 99.2/25.2
R84 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 99.2/23.9
C10 4030016930 S.CER ECJ0EB1A104K B 84.4/18.4
C11 4030017030 S.CER ECJ0EB1A273K B 85.2/31.4
C12 4030017400 S.CER ECJ0EC1H220J B 86.1/21.2
C13 4030017640 S.CER ECJ0EC1H150J B 86.1/19.3
C14 4030017510 S.CER ECJ0EC1H680J B 86.1/17.5
C15 4030017730 S.CER ECJ0EB1E471K B 83.7/12.8
C16 4030016790 S.CER ECJ0EB1C103K B 85.4/23
C17 4030016930 S.CER ECJ0EB1A104K B 83.8/22.8
C18 4030017420 S.CER ECJ0EC1H470J B 103.4/8.2
C28 4030017460 S.CER ECJ0EB1E102K B 63.4/24.6
C30 4030016930 S.CER ECJ0EB1A104K B 82.6/7.5
C31 4030017460 S.CER ECJ0EB1E102K B 92.7/4.5
C33 4030017460 S.CER ECJ0EB1E102K B 4.1/16.4
C35 4030017420 S.CER ECJ0EC1H470J B 94.7/4.5
C36 4030017460 S.CER ECJ0EB1E102K B 21/25.7
C37 4030017420 S.CER ECJ0EC1H470J B 7.2/9.2
C38 4030017420 S.CER ECJ0EC1H470J B 91.4/10.6
C39 4030017460 S.CER ECJ0EB1E102K B 98.8/10.1
C41 4030017420 S.CER ECJ0EC1H470J B 96.9/10.9
C42 4030017420 S.CER ECJ0EC1H470J B 20.6/28.9
C43 4030017460 S.CER ECJ0EB1E102K B 25.8/13.8
C44 4030017420 S.CER ECJ0EC1H470J B 93.2/10.6
C45 4030018860 S.CER ECJ0EB0J105K B 9/9.2
C46 4030017420 S.CER ECJ0EC1H470J B 94.7/12.2
C47 4030017420 S.CER ECJ0EC1H470J B 18.1/14.7
C48 4030017460 S.CER ECJ0EB1E102K B 31.3/15.2
C49 4030016790 S.CER ECJ0EB1C103K B 27/16.8
C50 4550006540 S.TAN ECST1CY475R B 27.5/20.2
C51 4030017460 S.CER ECJ0EB1E102K B 12/19.7
C52 4030017420 S.CER ECJ0EC1H470J B 25.8/12.8
C53 4030004760 S.CER C2012 JF 1H 104Z-T B 85.9/5.3
C54 4510006120 S.ELE ECEV1ES4R7SR B 78.1/6
C55 4030004760 S.CER C2012 JF 1H 104Z-T B 87.8/5.3
C56 4030006900 S.CER C1608 JB 1H 103K-T B 80.7/7.1
C57 4550006050 S.TAN TEESVA 0J 106M8L B 84.9/9.7
C58 4030017730 S.CER ECJ0EB1E471K B 104.6/13.4
C59 4030017730 S.CER ECJ0EB1E471K B 102.8/13.4
C60 4030016930 S.CER ECJ0EB1A104K B 83.6/27
C61 4030016930 S.CER ECJ0EB1A104K B 59.5/32.2
C62 4030016930 S.CER ECJ0EB1A104K B 59.9/31.2
C63 4030016930 S.CER ECJ0EB1A104K B 59.4/30.2
C64 4030016930 S.CER ECJ0EB1A104K B 59.9/29.3
C65 4030016930 S.CER ECJ0EB1A104K B 60.4/28.4
[FRONT-B UNIT] (for IC-F1800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC2 1110005770 S.IC S-80942CNMC-G9C-T2 B 84.7/29.2
IC3 1140010770 S.IC HD64F3687FP B 76.3/20.8
IC4 1130005720 S.IC TC7W04F (TE12L) B 65.8/28.1
IC5 1130008560 S.IC TC75S51F (TE85L) B 29.1/15.1
IC6 1110005350 S.IC NJM2870F05-TE1 B 83.1/5.3
IC7 1130009120 S.IC SED1526F0A B 43.3/20.5
IC8 1130005640 S.IC TC4W53F (TE12L) B 9.4/5.5
IC9 1110005310 S.IC AN6123MS B 31.1/5.6
Q1 1590001330 S.TR DTA114EUA T106 B 62/32.7
Q2 1590000680 S.TR DTC114EUA T106 B 66.6/23.6
Q3 1530002850 S.TR 2SC4116-BL (TE85R) B 70.4/8.3
Q4 1590001050 S.TR DTC114TUA T106 B 73.3/8.3
Q5 1590001050 S.TR DTC114TUA T106 B 72.8/10.8
Q6 1590001050 S.TR DTC114TUA T106 B 103/11.5
Q7 1590001050 S.TR DTC114TUA T106 B 105.6/11.5
D1 1790000620 S.DIO MA77 (TX) B 84.9/14.7
D4 1790001250 S.DIO MA2S111-(TX) B 62.4/29.9
D5 1790000950 S.ZEN MA8056-M (TX) B 13.8/27
D6 1790000950 S.ZEN MA8056-M (TX) B 12.1/27
D7 1790000950 S.ZEN MA8056-M (TX) B 19.9/15.3
D8 1750000550 S.DIO 1SS355 TE-17 B 89.4/12
D9 1750000130 S.DIO DA204U T106 B 61.8/10.4
D10 1750000130 S.DIO DA204U T106 B 59.2/10.4
D11 1750000130 S.DIO DA204U T106 B 56.7/10.5
D12 1790001250 S.DIO MA2S111-(TX) B 72.3/28.9
X1 6050009520 S.XTL CR-520 (19.6608 MHz+) B 89.3/19.9
L1 6200003640 S.COL MLF1608E 100K-T B 10.7/8.9
R4 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 86.3/12.8
R5 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 85.6/16.1
R6 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 85.1/20.2
R7 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 83.8/16.4
R8 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 83.8/20.2
R9 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 54.6/19.5
R12 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.2/27.9
R14 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 65/31.4
R15 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 62.5/26.6
R16 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 61.3/30.2
R18 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 63.4/23.5
R19 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) B 70/10.7
R20 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 21.6/16.3
R21 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 21/27.7
R22 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 71/11.7
R24 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 30.8/17.3
R25 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 28.4/11.1
R26 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 27/15
R28 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 28.4/12
