S.=Surface mount
6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT-B UNIT] (for IC-F1800 series)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C66 4030017490 S.CER C1608 JB 1A 105K-T B 54.3/25.7
C67 4030017490 S.CER C1608 JB 1A 105K-T B 54.3/24.2
C68 4030017460 S.CER ECJ0EB1E102K B 53.4/21.1
C69 4030017460 S.CER ECJ0EB1E102K B 90.7/5.3
C70 4030017760 S.CER ECJ0EB1H222K B 28.4/12.9
C71 4030017460 S.CER ECJ0EB1E102K B 25.4/8
C72 4510004630 S.ELE ECEV1CA100SR B 25.9/5.1
C73 4550006050 S.TAN TEESVA 0J 106M8L B 35.5/4.5
C74 4030016930 S.CER ECJ0EB1A104K B 29.7/10.8
C75 4030016930 S.CER ECJ0EB1A104K B 34/8.1
C76 4030018860 S.CER ECJ0EB0J105K B 25.4/9.4
C79 4030016930 S.CER ECJ0EB1A104K B 31.5/10.5
J1 6510024520 S.CNR 12FLT-SM1-TB B 93.9/7.9
J2 6450002210 CNR 3017-8821 <KIN>
J4 6510022020 S.CNR 14FLT-SM1-TB
DS1 5030002810 LCD L4-0013TVY-1
DS2 5040002310 S.LED SML-311YTT86
DS3 5040002310 S.LED SML-311YTT86
DS7 5040002310 S.LED SML-311YTT86
DS8 5040002310 S.LED SML-311YTT86 T 131.6/30.4
DS9 5040002310 S.LED SML-311YTT86 T 131.6/20.4
DS10 5040002310 S.LED SML-311YTT86 T 131.6/10.4
DS11 5040002310 S.LED SML-311YTT86 T 84.9/27
DS12 5040002310 S.LED SML-311YTT86 T 74.9/27
DS13 5040002310 S.LED SML-311YTT86 T 64.9/27
DS14 5040002310 S.LED SML-311YTT86 T 54.9/27
DS15 5040002310 S.LED SML-311YTT86 T 44.9/27
DS16 5040002310 S.LED SML-311YTT86 T 34.9/27
DS17 5040002930 S.LED SML-512MW T86 T 108.3/14
DS18 5040002990 S.LED SML-512UWT86 T 100.3/14
DS19 5040002310 S.LED SML-311YTT86 T 147.9/30.4
DS20 5040002310 S.LED SML-311YTT86 T 147.9/20.4
DS21 5040002310 S.LED SML-311YTT86 T 147.9/10.4
DS22 5040002310 S.LED SML-311YTT86 T 67.1/8.5
DS23 5040002310 S.LED SML-311YTT86 T 81.6/8.5
DS24 5040002310 S.LED SML-311YTT86 T 52.6/8.5
DS25 5040002310 S.LED SML-311YTT86 T 38.1/8.5
DS26 5040002310 S.LED SML-311YTT86
W1 8900013690 CBL OPC-1425 (N=12,L=92)
EP1 8930065150 LCT SRCN-2781-SP-N-W
EP2 0910058070 PCB B 6175
IC1 1110005340 S.IC NJM12902V-TE1 B 75.1/36.2
IC2 1110006220 S.IC AK2346-E2 T 48.4/27.8
IC4 1130010100 S.IC LMX2352TMX T 75.6/56.2
IC6 1130009700 S.IC LC73872M-TRM T 11.4/28.7
IC8 1190001350 S.IC M62364FP 600D T 70.6/27.9
IC9 1110005340 S.IC NJM12902V-TE1 T 113/51.5
IC12 1110003490 S.IC TA31136FN (D,EL) T 25/28.7
IC13 1110005290 S.IC NJM2115V-TE1
[F1721D], [F1821D] only T 88/16.5
IC15 1110006230 S.IC NJM2711F-TE1
[F1721D], [F1821D] only B 86/19.1
IC16 1190002080 S.IC AD7476ARTZ-500RL7
[F1721D], [F1821D] only B 96.7/19.3
IC17 1130008810 S.IC TC7SH32FU (TE85L)
[F1721D], [F1821D] only B 122/19.2
IC18 1130011610 S.IC AK4550VT-E2
[F1721D], [F1821D] only T 97/18.5
IC19 1110006230 S.IC NJM2711F-TE1
[F1721D], [F1821D] only B 92.7/35.2
IC20 1140011880 S.IC HD64F2239TE16
[F1721D], [F1821D] only T 111/30.5
IC21 1130011620 S.IC TC7MET374AFK (EC)
[F1721D], [F1821D] only B 122/14
IC22 1130003830 S.IC TC7S04F (TE85R)
[F1721D], [F1821D] only T 120/21.3
IC23 1140010190 S.IC HD64F2268TF B 100.3/60.1
IC24 1110005730 S.IC S-80928CNMC-G8Y-T2
[F1721D], [F1821D] only T 116/17.5
IC25 1130011600 S.IC TC7MET541AFK (EC)
[F1721D], [F1821D] only B 122/8
IC26 1140009240 S.IC HN58X24128FPI B 80.7/69.7
IC28 1130010390 S.IC HN58X2416TI
[F1721D], [F1821D] only T 93.5/27
IC29 1150002110 IC S-AV33 (I) [F1710], [F1810]
1150002160 IC S-AV32 (I2) [F1721/D], [F1821/D]
IC30 1190001340 S.IC M62334FP 600C T 25.3/56.7
IC31 1180002590 S.REG XC6204B332MR
[F1721D], [F1821D] only T 110/11.5
IC32 1180002640 S.REG R1114N151B-TR
[F1721D], [F1821D] only T 105.5/11.5
IC33 1180002590 S.REG XC6204B332MR
[F1721D], [F1821D] only B 105.5/13.1
IC34 1110002750 S.IC TA75S01F (TE85R) B 153.1/35.8
IC35 1120002510 S.IC DS14C232TM T 109.1/98.4
IC36 1180001250 S.IC TA7808F (TE16L) B 120.8/76.7
IC37 1110002750 S.IC TA75S01F (TE85R) T 51.3/84.1
IC38 1110003090 IC LA4425A
IC39 1110005800 IC TA8225L
IC40 1180000970 S.IC AN78L05M-(E1) B 138.3/78.4
IC41 1140011890 S.IC TMS320VC5416PGE120
[F1721D], [F1821D] only B 111/30.5
IC42 1130008230 S.IC BU4053BCFV-E2 T 61.3/10.7
IC43 1130008230 S.IC BU4053BCFV-E2 B 61.3/18.7
IC44 1110002750 S.IC TA75S01F (TE85R) B 70.3/7.6
IC45 1130007570 S.IC BU4094BCFV-E2 T 129.9/53.2
IC46 1110005770 S.IC S-80942CNMC-G9C-T2 T 98.5/68.5
IC47 1130007020 S.IC TC7S66FU (TE85R) B 49.1/41.2
Q1 1530002850 S.TR 2SC4116-BL (TE85R) B 37.5/28.4
Q2 1590001330 S.TR DTA114EUA T106 T 28.2/18.1
Q3 1530002600 S.TR 2SC4215-O (TE85R)
[F1721D], [F1821D] only T 82.9/38.8
Q4 1560000540 S.FET 2SK880-Y (TE85R) T 72.9/49
Q5 1590000430 S.TR DTC144EUA T106 B 74.2/61.5
Q6 1530002600 S.TR 2SC4215-O (TE85R) T 25.8/36.3
Q7 1590000430 S.TR DTC144EUA T106 T 121.5/51.7
Q9 1530002850 S.TR 2SC4116-BL (TE85R) B 69.5/45.3
Q10 1530002600 S.TR 2SC4215-O (TE85R) B 34.1/44.7
Q11 1530002920 S.TR 2SC4226-T1 R25 T 55/51
Q12 1530002920 S.TR 2SC4226-T1 R25 T 59.5/51
Q13 1560000990 S.FET PMBFJ310 B 34.1/52.7
Q14 1560000990 S.FET PMBFJ310 B 30.9/52.7
Q15 1590000720 S.TR DTA144EUA T106 T 108.9/58.5
Q17 1590001400 S.TR XP1214 (TX) B 57.1/44.8
Q18 1590000430 S.TR DTC144EUA T106 B 54.6/42
Q19 1530003310 S.TR 2SC5107-O (TE85R) B 65/56.9
Q20 1530003310 S.TR 2SC5107-O (TE85R) T 59.3/56
Q21 1530003310 S.TR 2SC5107-O (TE85R) B 52/64.6
Q22 1530003310 S.TR 2SC5107-O (TE85R) B 62.9/63.7
Q23 1530000370 S.TR 2SC3356-T1B B 64.8/91
Q24 1580000730 S.FET 3SK293 (TE85L) B 25.3/66.2
Q26 1560000840 S.FET 2SK1829 (TE85R) T 25.3/67.3
Q27 1590000430 S.TR DTC144EUA T106 T 103.8/77.8
Q28 1590000430 S.TR DTC144EUA T106 T 128.6/45.7
Q29 1590000990 S.TR DTC363EK T146 B 149.7/91.7
Q30 1510000920 S.TR 2SA1577 T106 Q T 108.2/80.8
Q31 1520000450 S.TR 2SB1132 T100 Q T 108.3/74.1
Q32 1590001190 S.TR XP6501-(TX) .AB T 103.8/74
Q33 1590001450 S.FET 2SJ144-GR (TE85R) B 147.8/19.5
Q34 1540000550 S.TR 2SD1664 T100Q B 118.8/82.8
Q35 1590001050 S.TR DTC114TUA T106 T 113.9/78.2
To Next Page
