S.=Surface mount
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
Q36 1530002850 S.TR 2SC4116-BL (TE85R)
[F1721/D], [F1821/D] only T 46.2/80.6
Q38 1590000430 S.TR DTC144EUA T106 B 148/30.4
Q39 1590000430 S.TR DTC144EUA T106 T 146.4/36.8
Q40 1590000430 S.TR DTC144EUA T106 B 142.9/38.4
Q41 1590000430 S.TR DTC144EUA T106 T 125.4/79.9
Q42 1550000020 S.FET 2SJ377 (TE16L) B 131.5/78.4
Q43 1590000430 S.TR DTC144EUA T106 B 87.8/66.3
Q44 1590000990 S.TR DTC363EK T146 B 146.1/35.8
Q45 1590000430 S.TR DTC144EUA T106 T 26.2/20.5
Q46 1530002850 S.TR 2SC4116-BL (TE85R) B 72.1/52.1
Q47 1530002850 S.TR 2SC4116-BL (TE85R) B 69.6/53.4
D2 1160000060 S.DIO DAN202U T106 B 26.9/17.1
D3 1790000620 S.DIO MA77 (TX) B 72.1/60
D4 1160000060 S.DIO DAN202U T106 B 27.9/24.5
D5 1790000620 S.DIO MA77 (TX) B 69.3/60
D6 1720000790 S.VCP HVC321B1TRF T 52.2/52.6
D7 1720000790 S.VCP HVC321B1TRF T 52.2/55.3
D8 1750000770 S.VCP HVC376BTRF T 64.7/49.8
D9 1750000770 S.VCP HVC376BTRF T 63.8/51.6
D10 1790001210 S.DIO 1SS375-TL T 32.2/33.9
D11 1750000720 S.VCP HVC375BTRF T 55.1/43.6
D12 1720000470 S.VCP 1SV239 (TPH3) T 65.5/44.6
D13 1750000720 S.VCP HVC375BTRF T 58.2/44.5
D14 1160000070 S.DIO DAN202K T146 B 110.8/68.9
D15 1790000620 S.DIO MA77 (TX) B 115.2/50
D16 1750000430 S.DIO HSB88WSTR T 42.8/62.5
D17 1750000710 S.VCP HVC350BTRF B 35.2/65.1
D18 1750000710 S.VCP HVC350BTRF B 32.1/65.1
D19 1790000620 S.DIO MA77 (TX) B 60.8/71.5
D20 1790000620 S.DIO MA77 (TX) B 58/67.5
D21 1750001080 S.DIO RB886G T2R T 66.5/102.5
D22 1790001250 S.DIO MA2S111-(TX) T 24.4/64.8
D23 1750000720 S.VCP HVC375BTRF B 17.6/64.8
D24 1790001250 S.DIO MA2S111-(TX) T 28.1/66.3
D25 1750000370 S.DIO DA221 TL T 24.9/62.4
D26 1750000720 S.VCP HVC375BTRF B 14.5/64.8
D27 1790000620 S.DIO MA77 (TX) B 13.6/72.4
D28 1790001240 S.DIO MA2S728-(TX) B 15.5/72.6
D29 1710001060 DIO XB15A407
[F1721/D], [F1821/D] only
D30 1750000510 S.DIO UM9401F [F1710], [F1810] only T 32.3/93
D31 1750000510 S.DIO UM9401F T 36.4/85.1
D34 1790001250 S.DIO MA2S111-(TX) B 146.7/90.7
D35 1790001210 S.DIO 1SS375-TL B 31.9/90.6
D36 1160000060 S.DIO DAN202U T106 T 128/42.8
D37 1750000370 S.DIO DA221 TL T 113.6/80.5
D38 1790001210 S.DIO 1SS375-TL B 11.3/79.3
D39 1790001250 S.DIO MA2S111-(TX) B 151.6/19.5
D40 1790001210 S.DIO 1SS375-TL B 4.4/100.6
D41 1790001240 S.DIO MA2S728-(TX) T 54.4/81.1
D44 1160000070 S.DIO DAN202K T146 B 89.4/75.9
D46 1790000700 DIO DSA3A1
D47 1160000070 S.DIO DAN202K T146 B 83.9/76.2
D48 1160000070 S.DIO DAN202K T146 B 95.2/77.7
D49 1790001250 S.DIO MA2S111-(TX) B 144/35.7
D51 1160000050 S.DIO DAP202U T106 B 139.9/19.3
D52 1160000050 S.DIO DAP202U T106 B 138.5/15.8
D53 1790001250 S.DIO MA2S111-(TX) T 126.1/42.9
D54 1160000050 S.DIO DAP202U T106 T 134.2/13.8
D55 1160000050 S.DIO DAP202U T106 B 140.8/10.9
D57 1750000130 S.DIO DA204U T106 T 113.1/103.8
D58 1750000130 S.DIO DA204U T106 T 110.6/103.8
D59 1750000130 S.DIO DA204U T106 T 105.6/103.8
D60 1750000130 S.DIO DA204U T106 T 108.1/103.8
D61 1790001250 S.DIO MA2S111-(TX)
[F1721D], [F1821D] only T 124.6/40.6
D62 1790001250 S.DIO MA2S111-(TX)
[F1721D], [F1821D] only T 119.7/36.5
D64 1160000050 S.DIO DAP202U T106 B 143.8/10.9
D65 1790001250 S.DIO MA2S111-(TX) B 138/20.5
D66 1750000130 S.DIO DA204U T106 B 129.5/102.9
D67 1750000130 S.DIO DA204U T106 T 102.5/103.8
D68 1750001080 S.DIO RB886G T2R T 67.6/102.5
FI1 2020001270 CER CFWLB450KE2A-B0
FI2 2020001410 CER CFWLB450KGFA-B0
FI3 2020001780 S.CER CFWCA450KEFA-R0
[F1721D], [F1821D] only T 83.7/28.5
FI4 2030000410 S.MLH FL-380 MFT46.3P 46.350MHz T 32.6/41.1
FI5 2040001440 S.LC NFE31PT152Z1E9L B 85.2/103.6
FI6 2040001440 S.LC NFE31PT152Z1E9L B 85.2/100.3
FI7 2040001440 S.LC NFE31PT152Z1E9L B 85.2/97
X1 6050011730 S.XTL CR-765 (3.6864 MHz) B 47.4/18.6
X2 6050012050 S.XTL CR-794 (15.3 MHz) B 79.9/44.4
X3 6050009910 S.XTL CR-563 (3.579545 MHz) B 10.7/26.1
X4 6070000190 S.DCR CDBCB450KCAY24-R0 T 17.9/36.7
X5 6050009520 S.XTL CR-520 (19.6608 MHz) B 121.8/56.3
X6 6050012130 S.XTL CR-802 (12.288 MHz)
[F1721D], [F1821D] only B 90.4/27.3
L1 6200004660 S.COL MLF1608A 1R8K-T T 76.4/63.3
L2 6200003540 S.COL MLF1608D R22K-T B 35.4/27.6
L3 6200004480 S.COL MLF1608D R82K-T B 30.1/27.6
L4 6200005690 S.COL ELJRE 18NG-F B 75/57.8
L6 6200007170 S.COL MLF1608A 3R3K-T T 50.9/55.3
L7 6200008400 S.COL 0.35-1.6-6TL 36N T 54.7/56.1
L8 6200003640 S.COL MLF1608E 100K-T T 50.9/52.7
L9 6200002610 S.COL NL 252018T-R47J T 66/52.7
L10 6200009460 S.COL 0.25-1.9-7TL 67N T 62.9/54.4
L11 6200003640 S.COL MLF1608E 100K-T T 66.6/47.3
L12 6200009460 S.COL 0.25-1.9-7TL 67N T 51.9/47.4
L13 6200007170 S.COL MLF1608A 3R3K-T T 52.6/44.5
L14 6200008190 S.COL 0.25-1.9-8TL 80N T 63/46.9
L15 6200007170 S.COL MLF1608A 3R3K-T T 61/44.1
L16 6200003960 S.COL MLF1608A 1R0K-T
[F1721D], [F1821D] only T 101.2/17.4
L17 6200003550 S.COL MLF1608A 4R7K-T B 28.4/47.9
L18 6200001620 S.COL ELJFC 1R0K-F B 30.7/49.6
L19 6200003640 S.COL MLF1608E 100K-T B 26.8/52.7
L20 6200003960 S.COL MLF1608A 1R0K-T
[F1721D], [F1821D] only B 95.7/24.7
L21 6200005690 S.COL ELJRE 18NG-F B 67.2/57.6
L22 6130002960 S.COL 617DB-1327=P3 T 42.8/56.1
L23 6130002960 S.COL 617DB-1327=P3 T 42.8/67.9
L24 6200010390 S.COL ELJRE 33NJ-F B 48.7/60.3
L25 6200009160 S.COL ELJRE 68NJ-F3 T 60.9/58.4
L26 6200010390 S.COL ELJRE 33NJ-F B 48.7/62.9
L27 6200009150 S.COL ELJRE 82NJ-F3 B 51.8/62.7
L28 6200007750 S.COL LQW2BHN56NJ01L B 37.9/65.2
L29 6200009150 S.COL ELJRE 82NJ-F3 B 61.9/65.9
L30 6200009150 S.COL ELJRE 82NJ-F3 B 67.1/92.4
L31 6200007750 S.COL LQW2BHN56NJ01L B 27.7/65.9
L32 6200008090 S.COL LQW2BHN68NJ01L B 20.2/64.6
L33 6200005740 S.COL ELJRE 47NG-F B 71.7/93
L34 6200005740 S.COL ELJRE 47NG-F T 74.2/96.6
L35 6200010050 S.COL AS080547-47N T 35.6/101
L36 6200008090 S.COL LQW2BHN68NJ01L B 11.8/64.6
L37 6200007750 S.COL LQW2BHN56NJ01L B 10.9/70.2
L38 6200010420 S.COL FHW1210HC 1R0JGT B 37.4/95.9
L39 6200006990 S.COL ELJRE 56NG-F B 18.9/73.4
L40 6200010050 S.COL AS080547-47N T 31.6/85.4
L41 6200002860 S.COL NL 252018T-4R7J T 104/62
L42 6200010050 S.COL AS080547-47N T 23.3/85.9
L43 6200010050 S.COL AS080547-47N T 14.3/85.5
L44 6200010050 S.COL AS080547-47N T 8.4/103
L45 6200003960 S.COL MLF1608A 1R0K-T
[F1721D], [F1821D] only T 115.2/20.6
L46 6200005700 S.COL ELJRE 22NG-F B 77.9/58.3
L47 6200005700 S.COL ELJRE 22NG-F B 78.6/56.5
R1 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 75.2/32.5
R2 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 82.5/36.9
R3 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 73.5/22.2
R4 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 67.7/17.7
R5 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 81.8/33.8
R6 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 48.5/28
R7 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 47.3/38
R8 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 148.2/7.3
R9 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 47.3/36.2
R10 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 49.4/33.2
R11 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 51.2/22.7
R12 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 52.5/16
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 134.2/22.1
R14 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 145.5/16.1
R15 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 144.6/16.1
R16 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 143.7/16.1
R17 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 142.6/17.8
R18 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 142.1/12.9
R19 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 137.6/18.8
R20 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 141.2/13.1
R21 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 81.5/37.9
R22 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 79.5/37.9
R23 7410001130 S.ARY EXB28V102JX T 78.3/64.5
R24 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 79.5/34.3
R25 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 81.8/34.8
R26 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 49.8/32.7
R27 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 50.8/32.7
R28 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 52.1/33.2
R29 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 58.4/28.7
R30 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 67.1/10.4
R31 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 59.9/30.2
R32 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 67.1/14.3
R33 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 143.7/13.3
R34 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 144.6/13.3
R35 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 145.5/13.3
R36 7410001130 S.ARY EXB28V102JX T 72.9/17.5
R37 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 37/25.6
R38 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 37.9/30.1
