Icom IC-F1721/D User Manual

S.=Surface mount
6 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R39 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 67.4/35.5
R40 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 69.2/35.5
R41 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 49.2/22.7
R42 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 54.4/25.4
R43 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 54.4/26.4
R44 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 50.2/20.7
R45 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 51.2/21.7
R46 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 6.9/26.1
R47 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 5.9/26.1
R48 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 77.9/49.4
R49 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) B 76.7/55.7
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 26.5/14.3
R52 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 65.6/35.5
R53 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 75/35.3
R54 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 58.3/25.9
R55 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 67.8/37.4
R56 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 110.8/45.4
R57 7510001730 S.TMR ERTJOEP 473J T 87.2/47.8
R58 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 87.2/49.6
R59 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 29/17
R60 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 66.5/38
R62 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 71.2/38.1
R67 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only T 84.8/38.3
R68 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only T 80.5/39.5
R69 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only T 80.5/38.2
R77 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 75.7/49.1
R78 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 72.3/46.7
R79 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 71/49.5
R80 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 67.3/54.3
R81 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 73.5/59.4
R82 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 70.7/59.4
R83 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 66.8/52.8
R84 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 70.6/61.6
R85 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 24.9/23.7
R86 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 24/26.1
R87 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 26.3/21.4
R88 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 28.9/21.3
R89 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 29.9/23.1
R90 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 76.5/24.8
R91 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 67.7/22.2
R92 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 66.8/22.2
R93 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 112.6/66.2
R94 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 135.8/5.3
R95 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 116.7/48.5
R96 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
)
[F1721D], [F1821D] only T 81.5/35.1
R97 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 72.4/43.9
R98 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 73.4/40.4
R99 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 29.7/24.9
R100 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 27.1/24.2
R101 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) T 27.1/22.3
R102 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) T 33.5/24.2
R103 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30.7/23.2
R104 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 30.7/24.2
R105 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 28.6/30.7
R106 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 119.3/53.8
R107 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 116.7/53.8
R108 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 109.7/52.1
R109 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 109.3/53.5
R110 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F1721D], [F1821D] only T 85.5/13
R111 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F1721D], [F1821D] only T 87.3/14
R112 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only T 83.5/14.8
R113 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
)
[F1721D], [F1821D] only T 83.5/16.5
R114 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only T 92.8/15
R115 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only T 103.1/42.8
R116 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
)
[F1721D], [F1821D] only T 89.1/14
R117 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
)
[F1721D], [F1821D] only B 84/15.5
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only B 83/15.5
R119 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
)
[F1721D], [F1821D] only B 83.2/20.3
R120 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 86.1/21.3
R121 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
)
[F1721D], [F1821D] only B 88.3/19.2
R122 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F1721D], [F1821D] only B 90.6/20.3
R123 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 85.5/15
R124 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only B 84/17.3
R125 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 74.2/42.9
R126 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 72.4/42.9
R127 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 71.2/45.7
R128 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 48.7/43
R129 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 24.3/33.4
R130 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 22.4/38
R131 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 23.9/38.5
R132 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 27.7/36.9
R133 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 30/35.6
R134 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 115.7/55.8
R135 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 117.2/56.1
R136 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 112.3/56.3
R137 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 112.3/58.1
R138 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only T 85/18.7
R139 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
)
[F1721D], [F1821D] only T 82.5/17.5
R140 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only T 81.5/17.5
R141 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only T 99.5/10.6
R142 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
)
[F1721D], [F1821D] only T 101.5/11.9
R143 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F1721D], [F1821D] only B 98.5/40.3
R144 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
)
[F1721D], [F1821D] only B 93.2/18.3
R145 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
)
[F1721D], [F1821D] only B 94.5/18.9
R146 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
)
[F1721D], [F1821D] only B 94.5/20.8
R147 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) T 55.3/46.9
R148 7030011000 S.RES RR0510P-392-D (3.9 k
Ω
) T 58.8/46.8
R149 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 62.2/41.5
R150 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 64.9/43.2
R151 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 26.7/39.5
R154 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 36.6/44.1
R155 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 36.1/44.5
R156 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 116.2/57.1
R157 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 115.3/58.9
R158 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 116.2/58.9
R159 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 117.1/58.1
R160 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 112.3/59.9
R161 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 119.4/57.6
R162 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 118/58.1
R163 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 118.9/58.9
R164 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 91.1/23.2
R165 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only T 80.5/18.5
R166 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
)
[F1721D], [F1821D] only T 81/19.8
R167 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F1721D], [F1821D] only T 97.8/14.2
R168 7030010040 S.RES ERJ2GE-JPW
[F1721D], [F1821D] only T 100.2/15.3
R169 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only T 97/36.9
R170 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only B 100.7/39.7
R171 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
[F1721D], [F1821D] only B 97.7/25.8
R172 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only B 115.8/17.4
R173 7030010040 S.RES ERJ2GE-JPW T 54.3/48.7
R174 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) T 53.2/50.5
R175 7030008340 S.RES RR0510P-182-D (1.8 k
Ω
) T 61.2/50.9
R176 7030009280 S.RES ERJ2GE T 56.3/48.7
R177 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 55/40.2
R178 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 58.8/48.6
R179 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 57.8/48.6
R180 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 31.6/44.7
R181 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 33.9/46.9
R182 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 29.5/46.6
R184 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 28.5/53.2
R185 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 104.5/59.3
R186 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 105.7/56.2
R187 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 112.7/51.8
R188 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 108/54
R189 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 116.7/51.4
R190 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 119.2/49.4
R191 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 114.9/53
R192 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 115.7/39.4
R193 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 65/59.6
R194 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 56.5/41.5
R195 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 45.5/57.2
R196 7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) B 45.5/58.2
R197 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 46.8/57.7
R198 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 109.9/61.3
R199 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F1721D], [F1821D] only B 93.6/25.5
R201 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
)
[F1721D], [F1821D] only B 90/33.8
