S.=Surface mount
6 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R202 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only B 90/32.8
R203 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only B 92/32.8
R204 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 120.7/24.4
R205 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 118.2/15.7
R206 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 117.9/14.2
R207 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 117.8/11.7
R208 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 61.1/56.9
R209 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 63.1/57.6
R210 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 63/61.2
R211 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 61.1/64.1
R212 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 65/55.1
R213 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 54.5/62
R214 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 54.5/65
R215 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 52.4/66.4
R216 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 64.9/63.6
R217 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 54.5/67
R218 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 34.7/62.5
R219 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 32.6/62.5
R220 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 33.1/61.2
R221 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
)
[F1721D], [F1821D] only B 95.9/35.2
R222 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 121.7/23.9
R223 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 119.7/19.2
R224 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 116.7/11.6
R225 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 115.4/11.6
R226 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 113.9/10.1
R227 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 112.9/10.1
R228 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
)
[F1721D], [F1821D] only B 111.9/10.1
R229 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only B 118.3/9.5
R230 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only B 116.5/8.7
R231 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only B 118.4/8.2
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only B 116.5/7.6
R233 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
)
[F1721D], [F1821D] only B 118.3/7
R234 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only T 122/6.5
R235 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 113.2/6.7
R236 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 116.3/5.2
R237 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 61.9/65.9
R238 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 63.3/73.8
R239 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) B 61.3/73.8
R241 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 68.2/92.7
R242 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 64.6/96.3
R243 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 60.6/62.8
R244 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 54.5/66
R245 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 58/65.8
R246 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 58/63.2
R247 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 61.3/68.5
R248 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 62.1/90
R250 7030003310 S.RES ERJ3GEYJ 820 V (82
Ω
) B 61.4/92.7
R251 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 60.3/90
R252 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 29.4/61.8
R253 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 22.2/62.3
R254 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 22.2/64.1
R255 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 24.1/68.1
R256 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 23.3/65.3
R257 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 30/65.4
R258 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 24.2/64.1
R259 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 23.3/66.1
R261 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 101.7/63.7
R262 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 82.5/64.8
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 80.4/65.4
R264 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 99.2/61.7
R268 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only B 126.6/6.1
R269 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 125.7/9.7
R270 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 128.3/9.7
R271 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 128.3/8.7
R272 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 128.3/7.7
R273 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
)
[F1721D], [F1821D] only B 125.7/7.7
R276 7030010040 S.RES ERJ2GE-JPW T 75.4/99.5
R277 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 22.4/67.6
R278 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 27.7/68
R279 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 26.7/65.6
R280 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 26.2/64.2
R281 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 64.7/99.7
R282 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 17.1/62.1
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 15/62.1
R284 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 16.6/60.8
R285 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 97.1/70
R286 7410000730 S.ARY EXB-V8V 104JV (100 k
Ω
) T 101/52.1
R287 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 91.9/49.2
R288 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 92.1/50.7
R290 7410000830 S.ARY EXB-V4V 103JV (10 k
Ω
)
[F1721D], [F1821D] only T 98.8/24.6
R291 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 98/27.8
R292 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 99/28.3
R293 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 64.7/101.9
R294 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 64.7/100.7
R295 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 64.7/102.9
R296 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 29.7/56.6
R297 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 30.2/58.6
R298 7030004010 S.RES ERJ3GEYJ 2R2 V (2.2
Ω
)
[F1721D], [F1821D] only B 108.1/13.5
R299 7030006070 S.RES ERJ12YJ101U (100
Ω
) B 43.1/95.9
R300 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 144.6/90.7
R301 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 149.1/17.1
R302 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 148.2/5.6
R303 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 30.1/90.2
R304 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 129.7/43.2
R305 7410000950 S.ARY EXB-V8V 102JV T 106.9/92.4
R306 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 148.2/11.1
R307 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 146.4/17.8
R308 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 105.6/77.2
R309 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 111.9/78.2
R310 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 106.1/78.7
R311 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 108.2/78.7
R312 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 101.9/73.5
R313 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 9.3/80.1
R314 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 14.5/78.7
R315 7030000220 S.RES MCR10EZHJ 47
Ω
(470) B 3.4/83.6
R316 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 52.8/86.4
R317 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 33.7/90.2
R318 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 49.1/86.5
R319 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
)
[F1721/D], [F1821/D] only B 44.2/92.8
R320 7520000240 S.POS PRF18BC471QB1RB
[F1721/D], [F1821/D] only T 37.8/90.1
R321 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) T 141.4/79.1
R322 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 145.1/84.1
R323 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 151.7/89.2
R324 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 152.7/93.2
R325 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 151.4/38.9
R326 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 152.4/33.6
R327 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 154.4/31.6
R328 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 149.1/68.3
R329 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 154.4/33.6
R332 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 150.4/34.7
R333 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 149.2/21.2
R334 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 146.4/21.3
R335 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 151.9/18.4
R336 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 154.4/23.9
R337 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 147.2/21.9
R338 7030000480 S.RES MCR10EZHJ 6.8 k
Ω
T 120.3/79.1
R339 7030000480 S.RES MCR10EZHJ 6.8 k
Ω
T 118.3/79.1
R340 7030000220 S.RES MCR10EZHJ 47
Ω
(470) B 16.4/100.4
R341 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 2.6/100.8
R342 7030003370 S.RES ERJ3GEYJ 271 V (270
Ω
) B 7.2/100.6
R343 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 53.5/84.1
R344 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 50.3/81.1
R345 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 52.3/81.1
R346 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 49.1/81.1
R347 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 48.1/81.1
R348 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 153.4/91
R349 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 152.4/38
R350 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 152.2/78.3
R351 7030003300 S.RES ERJ3GEYJ 680 V (68
Ω
) T 142.6/71.2
R352 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 142/59.5
R353 7030003300 S.RES ERJ3GEYJ 680 V (68
Ω
) T 151.4/66.7
R354 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 154.2/38
R355 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 152.7/70.4
R359 7030000440 S.RES MCR10EZHJ 3.3 k
Ω
T 116.3/79.1
R360 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 131.3/83.7
R361 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 127.1/81.3
R362 7030000620 S.RES MCR10EZHJ 100 k
Ω
B 6.3/105.2
R363 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 54.4/77.4
R364 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 53.2/81.1
R365 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 150.3/109
R366 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 143.6/71.2
