Icom iC-F3033S User Manual

19
4
BATTERY CHARGING
Rapid charging with the BC-121N+AD-106 D
The optional BC-121N allows up to 6 Li-ion battery packs to
be charged simultaneously. The following items are addition-
ally required.
s 3IX !$ CHARGER ADAPTERS
s An optional AC adapter or the DC power cable (OPC-656)
Battery
pack
AD-106 charger
adapters are installed
in each slot.
AC adapter
(Purchased
separately)
Transceiver
DC power cable (OPC-656)
(Connect with the DC power supply; 13.8 V/at least 7 A)
*Abou the OPC-656
Red line : Black line :
Tu rn power OFF
IMPORTANT: Battery charging caution
Ensure the guide tabs on the battery pack are correctly
aligned with the guide rails inside the charger adapter.
(This illustration is described with the BC-160.)
Guide rail
Tabs
