2 - 1
SECTION 2
.
INSIDE
VIEWS
• FRONT UNIT
CPU
(IC51)
LCD DRIVER
(IC6)
MIC AMP
(IC7)
MIC GAIN SW
(IC53)
EEPROM
(IC52)
CLOCK FREQUENCY
SHIFT DIODE
(D60)
CPU CLOCK
(X51)
BA
CKLIGHT SW
(Q5)
DIMMER CONTROLLER
(Q2)
MIC AMP FREQUENCY
RESPONSE SW
(IC54)
BA
CKLIGHT LED DRIVER
(Q1)
5
7
Table of Contents
Default Chapter
3
Table of Contents
3
Specifications
4
Section 2 Inside Views
6
Section 3 Disassembly Instruction
9
Section 4 Optional Cable Installation
10
Receiver Circuits
11
Transmitter Circuits
12
Frequency Synthesizer Circuits
13
Voltage Diagram
13
Port Allocations
14
Section 6 Adjustment Procedure
15
Preparation
15
Frequency Adjustment
18
Transmit Adjustment
19
Receive Adjustment
21
Parts List
22
