9. Line in gain level control
This potentiometer controls the input level of the Line-in inputs.
10. LCD backlit display
The two-line backlit LCD display shows the parameter values as you adjust them
and also provides feedback about channel selections, operating modes, and
more.
11. FX/Vocal Tune/Pitch Shift/EQ control knobs
These two encoders are provide to adjust the settings and parameters of FX,
Vocal Tune, Pitch Shift and EQ
12. FX/Vocal Tune/Pitch Shift/EQ display LED
These LEDs show the active control settings on the LCD. Press the left control
knob to switch the active control manual from FX, Vocal Tune, Pitch Shifty or
EQ.
13. Signal ow control buttons – Recording/Live Streaming &
Monitoring
There are mainly two group of buttons (2x4) controlling the “Recording/Live
Streaming” and “Monitoring” signal ow.
Recording/Live Streaming button group consists of:
Dry
Only Mic/Inst input signal will be recorded or live streamed (no
DSP processed).
Wet
Mic/Inst input signal with DSP processed will be recorded or live
streamed.
Line In
Only Line in input signal will be recorded or live streamed (Note: If
LiveRemote is being used, its signal will also blend with the Line in
signal)
PC Out
PC or Smart Phone playback signal will be recorded or live
streamed.
Monitoring button group consists of:
Dry Only monitoring the Mic/Inst. input signal.
Wet Monitoring Mic/Inst. input signal with DSP processed.
Line In Monitoring the Line in signal
PC Out Monitoring the PC or Smart Phone playback
