14. LiveRemote sensor
 An optional device “LiveRemote” is available for triggering sound sampler remotely
when you doing live streaming. Please contact our dealer nearest you for product
information.
15. Mode button
 Press to switch & activate between different channel signal ow presets including:
P0 Custom
Chan
Allow you to self dene your desired channel signal ow by
activating the different buttons on “Recording/Live Streaming” and
“Monitoring” button group
P1 Chat Intended for internet chatting application
P2 Music Intended for music listening application
P3 Gaming Intended for internet gaming application
P4 Host Intended for host live streamer
P5 KTV Intended for internet karaoke application
P6 Record
Dry
Intended for dry recording application
Please refer to the below chart for the relation between the activated buttons
at each preset mode
Recording/Live Streaming Monitoring
Mode Dry Wet Line-In PC Out Dry Wet Line-In PC Out
P0 Custom
Chan
User seif dene as will
P1 Chat Activated Activated Activated
P2 Music Activated Activated
P3 Gaming Activated Activated
P4 Host Activated Activated Activated Activated Activated
P5 KTV Activated Activated Activated Activated Activated Activated Activated
P6 Record
Dry
Activated Activated Activated Activated Activated Activated
