19
PMX-090T DM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
IRQ Mapping
IRQ#
Description
Usage
IRQ0
System Timer
*
IRQ1
Keyboard Controller
*
IRQ2
Cascade for IRQ8 - 15
IRQ3
USB
*
IRQ4
Serial Port 1
*
IRQ5
USB
*
IRQ6
Unassigned
IRQ7
Ethernet 10/100M LAN
*
IRQ8
Real Time Clock
*
IRQ9
USB
*
IRQ10
USB
*
IRQ11
Audio
*
IRQ12
Mouse
*
IRQ13
Math Coprocessor
*
IRQ14
Hard Disk Controller#1
*
IRQ15
Hard Disk Controller#2
*
DMA Mapping
DMA#
Description
Usage
DMA0
DMA1
DMA2
Floppy Disk Controller
DMA3
DMA5
DMA6
DMA7
