TPD/VPD Series HMI Device User Manual
Copyright © 2020 ICP DAS Co., Ltd. All Rights Reserved. Page: 7
1.2 Module Naming Convention
There are many different products available, and sometimes it is difficult to remember the
specifications for any given product. However, if you take a few minutes to understand the module
naming conventions, it may save your time and prevent confusion. The figure below shows how the
module naming conventions work for each TPD/VPD series product.
Touch Screen Size
Communication Interface
Special
28: 2.8 inch
43: 4.3 inch
70: 7.0 inch
For 2.8 inch:
0: RS-485
0U: RS-485 + RTC
3: Ethernet
3U: RS-485 + RTC
+ Ethernet
For 4.3 inch:
0: RS-485
2: RS-485 x 2
3: RS-485/RS-232
+ Ethernet
(F): Flat Type
For 7.0 inch:
3: Ethernet
+RTU
EU: For European 86 x 86 mm
Outlet Box
H: High Speed Version
M1 ~ M3: Stylish Panel
64: 64 MB SDRAM/64 MB Flash
Form Factor
Touch Screen Size
Communication Interface
Special
1: 103 x 103 mm Panel Mount
3: 3.5 inch
4: 4.3 inch
7: 7 inch
0: RS-485
2: RS-232/RS-485 + RS-485
3: RS-232/RS-485 + RS-485 +
Ethernet
(N): No Rubber Keypad
H: High Speed Version
64: 64 MB SDRAM/64
MB Flash
