ICP C9MPT050F12C1 User Manual

Exterrnal Static Pressure
(in wc)
Exterrnal Static Pressure
(in wc)
Exterrnal Static Pressure
(in wc)
Exterrnal Static Pressure
(in wc)
3
440 04 2023 02
Specifications are subject to change without notice
Circulation Air Blower Data - *9MPT
*9MPT050F12 (1) * Denotes Brand
Speed
Tap
Low Med L Med H Hi
0.1 826 1083 1301 1408
0.2 804 1050 1242 1347
0.3 770 1028 1195 1295
0.4 735 985 1153 1237
0.5 698 952 1093 1183
0.6 657 909 1040 1118
0.7 -- -- -- 863 935 1053
0.8 -- -- -- -- 812 865 976
0.9 -- -- -- -- -- -- 802 887
1.0 -- -- -- -- -- -- 720 787
*9MPT100J16 (1) * Denotes Brand
Speed
Tap
Low Med L Med H Hi
0.1 823 1109 1527 1850
0.2 795 1087 1482 1791
0.3 747 1056 1426 1720
0.4 677 1016 1382 1648
0.5 617 970 1317 1575
0.6 544 854 1245 1485
0.7 -- -- -- 763 1154 1401
0.8 -- -- -- 652 1043 1284
0.9 -- -- -- -- -- -- 905 1161
1.0 -- -- -- -- -- -- 737 1028
*9MPT075F14 (1) * Denotes Brand *9MPT125L20 (2) * Denotes Brand
Speed
Tap
Low Med L Med H Hi
0.1 695 1025 1455 1724
0.2 674 1001 1410 1662
0.3 653 951 1365 1601
0.4 631 921 1309 1530
0.5 609 891 1252 1460
0.6 569 845 1187 1380
0.7 529 799 1122 1300
0.8 490 730 1030 1190
0.9 -- -- -- 680 950 1080
1.0 -- -- -- -- -- -- 831 969
NOTE: (1) Data based on Bottom Only or One Side return.
(2) Data based on Both Sides or Bottom plus One Side
MAX CFM’s for Factory
Washable Filters
Filter Size CFM
14″ X25″ 1400
16″ X25″ 1600
20″ X25″ 2000
24″ X25″ 2500
Max CFM based on 600 FPM
NOTE: Disposable filters are typically rated at 300 FPM. These filters only allow
half the airflow when compared to 600 FPM filters. (EXAMPLE, 20 X 25 @ 600
FPM = 200 CFM, @ 300 FPM = 1000 CFM)
Speed
Tap
Low Med L Med H Hi
0.1 1720 1910 2127 2315
0.2 1686 1881 2087 2268
0.3 1644 1833 2024 2201
0.4 1600 1777 1961 2131
0.5 1533 1720 1891 2029
0.6 1494 1647 1804 1948
0.7 1413 1571 1708 1820
0.8 1306 1470 1604 1730
0.9 -- -- -- 1349 1484 1614
1.0 -- -- -- -- -- -- 1328 1430
# CFM -- Cubic feet per minute airflow. Filter required for each return--air
inlet. Airflow performance includes 1″ washable (600 FPM max) filter media.

ICP C9MPT050F12C1 Specifications
