• Confirm that the Vertical Louver is normally geared with the shaft of
Stepping Motor.
• If the regular torque is detected when rotating the Vertical Louver with
hands ¢¡ Normal
• Check the connecting condition of CN-UP/DOWN Connector
• Check the soldering condition(on PWB) of CN-UP/DOWN Connector
Check the operating circuit of the Vertical Louver
• Confirm that there is DC
+
12V between pin¤Ł(RED) of CN-UP/DOWN and
GND.
• Confirm that there is a soldering short at following terminals.
- Between §œ, §ß, § and § of MICOM
- Between ¤Ø, ¤Œ, ¤ºand ¤ of IC7
- Between ¤æ, ¤ , ¤ and ¤ of IC7
- Between ¤ , ¤Ł, ¤Ø, ¤Œand ¤ºof CN-UP/DOWN
If there are no problems after above checks
• Confirm the assembly conditions that are catching and interfering parts in
the rotation radial of the Vertical Louver
6. When Vertical Louver does not operate.
To Next Page
