SPECIFICATIONS
1
Model
ICSW7C ICSW22C
Voltage and Wiring 230V AC single-phase: LIVE, 400V AC three-phase: L1, L2, L3,
Current and Power Maximum 32A Maximum 32A
Frequency
50-60 Hz
Internal RCD
AC 30mA, DC 6mA
Data Protocol
OCPP 1.6J
Charging Connector
IEC62196 Type-2 socket
Buttons
1 x Physical Button
RFID
ISO 14443 A/B
Display
2.8’’ LCD
Network Connectivity
Ethernet, WLAN, Cellular
Working Temperature
-30°C to 50°C
Storage Temperature
-40°C to 70°C
Working Humidity
5% - 95% without condensation
Dimension (H x W x D)
380 x 288 x 141 mm
Backplate Material
316 Stainless Steel
Weight
5.3Kg 5.4Kg
IP Rating
IP55
Certifications
EN 61851-1:2020, EN61851-21-2, EN 61000-3
SPECIFICATIONS
All specifications and descriptions contained in this document are
verified to be accurate at the time of printing. However, because
continuous improvement is a goal at iCS, we reserve the right to
make product modifications at any time.
FEATURES
2
PME EARTH FAULT MONITORING
The charger has been developed for installations to meet and comply
with wiring regulations BS7671:2018 including amendment 1:2020.
If installed on a TN-C-S (PME) system, a dedicated earth rod to the
charge point may not be required, as our hardware meets the
requirements of the revised regulation 722.411.4.1 for use of an open
protective earthed-neutral (PEN) detection device. Upon detection of
a fault, charging is stopped and the car isolated from the supply
(including earth ).
SELF-MONITORING AND RECOVERY
The charger will automatically reset after a minor fault such as Over
Voltage Protection (OVP), Under Voltage Protection (UVP), Over
Temperature Protection (OTP) or Over Current Protection (OCP),
with no user intervention required. Resetting of internal RCD or PME
faults can be configured to manual or automatic.
OCPP 1.6J FULL PROFILES & SMART CHARGING SUPPORT
The charger supports OCPP 1.6J full profiles, including the latest
smart charging to manage the load of charging stations with limited
power supply. iCS offer our own OCPP software, contact iCS for more
information.
