RDA5807 FM 87-108MHz Radio Receiver LCD1602 DIY Kit
3
29
Acrylic Board
6
30
M3*10mm Copper Pillar
4
31
M3*10mm Screw
4
32
M3*8mm Screw
4
33
M3*6mm Screw
14
34
Nut
18
35
PCB
82*64*1.6mm
1
Note:Users can complete the installation according to the PCB silk screen and
component list.
6. Schematic Diagram:
7..Note:
1>.It is a wireless module. So do not use it in an environment with signal
interference.
2>.There is a SMD component so that you can place it on PCB and then fix
by tin.
8.Installation Tips:
1>.User needs to prepare the welding tool at first.
1.1>.Soldering iron (<50 Watt)
