IP Address: Specify a unique IP address for the unit.
Subnet Mask: Specify the mask for the subnet the panel is located on
Gateway: Specify the IP address of the default router (Gateway) used for
connecting attached devices to different networks.
Primary DNS: Specify the IP address of the Primary DNS Server for your
network.
Secondary DNS: Specify the IP address of the Secondary DNS Server for your
network.
Web Server:
CAUTION:
Changing the web server port numbers may cause loss of communication with
the panel
The following ports may be changed within a range of 1 to 65565, if
required.
HTTP Port: This port is used for HTTP traffic between the panel and your
browser. The default HTTP port is 80, and if you change this the new HTTP
Port number must be appended to the URL used to access the panel. (e.g.
use URL http://192.168.0.180:8000 for IP address 192.168.0.180, port 8000)
HTTPS Port: The HTTPS (HTTP Secure) protocol uses encrypted data transfer
between web browsers and servers for higher security. The default HTTPS
port is 443. Append any changed HTTPS port to the end of the URL for the
panel.
To access the panel through a secure HTTPS connection, use https:// at the
start of the units URL. (e.g. https://192.168.0.180:8888 for IP address
192.168.0.180, HTTPS port 8888)
UDP Port: This port is used when applying firmware upgrades to the panel.
The default UDP port is 9393.
SNMP:
Configure these settings if you would like to use SNMP based monitoring. SNMP
(Simple Network Management Protocol) is an industry standard protocol for
network management software. Enabling the SNMP function on the panel will
