Manual IB-DK2246AC
Requirements
• USB Type-C
®
enabled Windows
®
/ macOS
®
/ Chrome OS
™
/ Ubuntu
(Linux) computer
• Installed DisplayLink
®
(Synaptics) driver
• Power Delivery, DP Alt Mode and/or DisplayLink
®
driver support (depen-
ding on your demands)
• The maximum resolution of 4K@60 Hz (Alt Mode HDMI
®
) only via Type-C
®
DP Alt Mode supported host computers
• The device is compatible with Thunderbolt
™
3 / 4 equipped computers
USB Type-C
®
Not all USB Type-C
®
host ports support the full functionality of the USB Type-C
®
standard. Some ports might only provide data transfer without supporting Power
Delivery or DP Alt Mode over USB.
To use this dock to its full potential, ensure that the USB Type-C
®
host port of your
computer supports USB Power Delivery and DP Alt Mode, or Thunderbolt
™
3 / 4.
Attention!
In case your computer supports only the DP Alt Mode protocol and the DisplayLink
®
driver is not installed:
- only the Alt Mode HDMI
®
(4K) interfaces can be used.
In case your computer does not support the DP Alt Mode protocol and only has USB
3.2 Gen 2 and the DisplayLink
®
driver installed:
- only the HDMI
®
/ DisplayPort
™
1 (4K) and HDMI
®
/ DisplayPort
™
2 (4K) interfa-
ces can be used.
USB version information
Legacy USB standards Current USB standards Data transfer rate
USB 3.0 = USB 3.1 (Gen 1) = USB 3.2 Gen 1 = 5 Gbit/s
USB 3.1 = USB 3.1 (Gen 1) = USB 3.2 Gen 1 = 5 Gbit/s
USB 3.2 (Gen 1x2) = USB 3.2 Gen 1x2 = 20 Gbit/s
USB Type-C
™
≠
USB Type-C
™
Important!
This ICY BOX product requires the usage of DisplayPort™ Alt Mode
technology over the USB Type-C™ connector. Not all computers,
notebooks or tablets with a USB Type-C™ interface support the
DisplayPort™ Alt Mode.
Please check the specifications of your computer system as
well as its USB Type-C™ interface or use the ICY BOX product with a
Thunderbolt™ 3 connector.
Computer
manual
