ID Lock 202 MULTI - Supported Command Classes and Configuration; Non-Secure Command Classes; Secure Command Classes; Configuration Parameters

idlock.no/zwave
Supported Command Classes
Non-Secure
Class
Value
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
5E
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
72
COMMAND_CLASS_SECURITY_V1
98
COMMAND_CLASS_DEVICE_RESET_LOCALLY_V1
5A
COMMAND_CLASS_POWERLEVEL_V1
73
COMMAND_CLASS_CONFIGURATION_V1
70
Secure
Class
Value
COMMAND_CLASS_VERSION_V2
86
COMMAND_CLASS_DOOR_LOCK_V2
62
COMMAND_CLASS_USER_CODE_V1
63
COMMAND_CLASS_ASSOCIATION_V2
85
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V1
59
COMMAND_CLASS_NOTIFICATION_V4
71
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
7A
COMMAND_CLASS_BATTERY_V1
80
Configuration Parameters
COMMAND_CLASS_CONFIGURATION (Default value BOLD)
Name
Parameter
Size
Value
Description
Lock Mode
1
1
0
Manual lock/Away off
1
Auto lock/Away off
2
Manual lock/Away on
3
Auto lock/Away on
RFID Mode
2
1
5
RFID reader activated
9
RFID reader deactivated
Hinge
Direction
3
1
0
Not used for IDL-202
1
Audio
Volume
4
1
0
Silent
1
Very low
2
Low
3
Medium low
4
Medium
5
Medium high
6
High
ReLock
Mode
5
1
0
ReLock off
1
ReLock on
Service PIN
Mode
(index 108)
6
1
0
Deactivated
1
1x use
2
2x uses
3
5x uses
4
10x uses
5
Random PIN 1x use
6
Random PIN 24h use
7
Always valid
8
12 hours use
9
24 hours use
FE
Disabled
Model Type
7
1
CA
CA = 202 (Read-only)
Updater
Mode
8
1
0
Off (no sound)
1
On (no sound)
2
Off
3
On
Master PIN
Unlocks
9
1
0
No
1
Yes
User Code
COMMAND_CLASS_USER_CODE_V1
Z-Wave identifier
ID Lock index
Description
1-25 (0x00 – 0x19)
1-25
User PINs
26-51 (0x1A – 0x32)
1-25
RFID key fobs
52-107 (0x33 – 0x6B)
-
Reserved for later use
108 (0x6C)
1
Service PIN
109 (0x6D)
1
Master PIN
User ID Status
Value
Description
0x00
Available (not set)
When user code is deleted
0x01
Occupied
When user code is registered
0xFE
Status not available
When user code is disabled
Notification Parameters
COMMAND_CLASS_NOTIFICATION (V4)
Type
Event
Description
Access
Control
(0x06)
0x01
Manual lock or key button lock
0x02
Manual unlock or key button unlock
0x03
Locked remotely (ID: 0)
0x04
Remotely unlocked (ID: 0) or
RFID Unlock (ID: Index)
0x05
Locked from keypad
0x06
Unlocked from keypad
0x09
Auto locked and ReLock
0x0B
Lock jammed
0x0C
All user codes deleted
0x0D
Single user code deleted
0x0E
Single user code added
0x0F
New code not added, duplicate
0x14
Unlock attempt unknown RFID
0x15
Unlock attempt unknown PIN
Home
Security
(0x07)
0x03
Door forced open
0x00
Idle
Notified after valid PIN is entered
Emergency
(0x0A)
0x02
Fire sensor triggered
0x00
Idle
Notified after valid PIN is entered
Notification examples
Keypad lock
Type
Event
Length
Value 1
0x06
0x05
0x01
0x00
Lock jammed
Type
Event
Length
0x06
0x0B
0x00
Unlock attempt unknown PIN «2 2 2 2»
Type
Event
Length
Value 1
Value 2
Value 3
0x06
0x15
0x02
0x01
0x22
0x22
Manufacturer parameter
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
Name
Value
Description
Manufacturer ID
0x0373
ID Lock AS
Product Type ID
0x03
PRODUCT_TYPE_ID_ZWAVE_PLUS
Product ID
0x01
PRODUCT_ID_DoorLockKeyPad
Association & Association Group Parameter
ID Lock support 1 association group with 5 devices.
Notification reports are sent unsolicited to devices included in the
association group.
Grouping identifier: 1
Name: Lifeline
Version Parameter
COMMAND_CLASS_VERSION_V2
Name
Value
Remark
Z-Wave Protocol Library Type
0x03
Z-Wave Protocol Version
0x04
Z-Wave Protocol Sub Version
0x05
Firmware 0 Version
0x01
Z-Wave Module with
firmware v1.6
Firmware 0 Sub Version
0x06
Hardware Version
0x01
Number of Firmware targets
0x01
Firmware 1 Version
0x01
ID Lock 150 with
firmware v1.5.6
Firmware 1 Sub Version
0x56
Revision:
1.0
Date approved:
2023-07-06
Approved by:
ØNB
Language:
English
