User Manual- 2 -
Overview
Features
TEOd9 is a four input, eight output professional Loudspeaker Management System. Available in four performance levels and using
only the best sounding components available, its unrivalled audio quality and feature set match the highest standards.
• Unparalleled audio quality
• State-of-the-art digital processing
• Programmable User Interface
• Monitoring and permanent logging of key parameters such as temperature,signal level and gain reduction
• 384, 600 or 1200 FIR taps per output
• Dante, AES67, AES/EBU and AVB/MILAN (est. Q1/2021)
• Multiple display and GPI / GPO support
• Full customization options
• 8 DC inputs for potentiometers
• 8 current measurement AC inputs
• 8 temperature sensor inputs
• 100Mbit LAN with loop through
• Direct Drive capability for single ended XLR outputs, or balanced drive with a suitable output driver card
Technical Drawings
480 mm
FRONT VIEW
SIDE VIEW (RIGHT)
165 mm
45 mm
