User Manual- 3 -
Technical Data
Inputs
Analog Inputs (electronically balanced) 4
Dynamic Range typ. 135 dB(A)
Max. Input Level +24 dBu
Input Impedance (balanced) 21 kΩ
Input Impedance (single ended) 10.5 kΩ
Digital Inputs up to 6
Outputs
Analog Outputs 8
Dynamic Range typ. 120 dB(A)
Maximum Output Level +18 dBu
Output Level Selection (by software) +6, +12, +18
Noise oor at lowest signal level setting typ. -110 dBu(A)
Source Impedance 157/235/470 Ω
Digital Outputs up to 6
System
Input-to-output latency 350 μs
Gain 0 +/- 0.5 dB
Dynamic Range (unity gain, +12dBu output level setting) typ. 120 dB(A)
THD (@ 0dBu, 1kHz, unity gain, DSP only) < 0.003 %
Frequency Response (DSP only) 10…40k Hz +/-0.5 dB
DSP 64 bit multimode ALLDSP AM685
Number of processors 4
Sample rate 96 kHz
FIR 8x600 taps
Presets 250
Delay 2000 (in) / 50 (out) ms
PEQ (each input and output) 10 bands
Crossover (each input and output, LPF and HPF) 48 dB/Oct
Compressors (each input and output) 3 bands
Limiter (switchable true RMS / Zero Attack, each in and out) 1 bands
Power Supply
Minimum analog supply voltage +/- 12 V
Recommended analog supply voltage +/- 15 V
Minimum low voltage supply (optional) 6 V
Current consumption +15V (with 6V supply) 150 mA 150 mA
Current consumption +15V (without 6V supply) 500 mA
Current consumption -15V 150 mA
Current consumption 6V 600 mA
Environmental
Temperature 0 to 50 ºC
Humidity < 80 %RH
Physical
Dimensions (W x H x D) 480 x 45 x 165 mm
Weight 2.5 kg
