Ideal Air 700021 - Page 20

North America
Appliance Amps (A)
AWG
10 18
13 16
18 14
25 12
30 10
Other Regions
Rated Current of
Appliance (A)
Nominal Cross-
Sectional Area (mm²)/in
2
> 3 and ≤ 6 0.75/.03”
> 6 and ≤ 10 1/.04”
> 10 and ≤ 16 1.5/.06”
> 16 and ≤ 25 2.5.10”
> 25 and ≤ 32 4/.16”
> 32 and ≤ 40 6/.24”
Cover
Outdoor Unit Wiring Diagram
is located on the inside of the
wire cover on the outdoor unit.
