Page 3
SPECIFICATIONS
All specifications are warranted unless noted typical and apply to the 61-095.
Stated accuracies are at 23ºC ± 5ºC at less than 80% relative humidity and without the battery
indicator displayed.
General specifications
Characteristics Description
LCD display digits 3 ½
Display count 2,000
Numeric update rate 2.5 times / sec
Polarity display Automatic
Overrange display “OL” is displayed
Low voltage indicator
is indicated
Automatic power-off time Automatic backlit off = 30 minutes
Power source One 9V dry cell battery
Maximum input voltage 600V CAT III between V and COM
Maximum floating voltage 600V CAT III between any terminal and earth ground
V connector V , V , Ω,
Temperature Coefficient 0.2 x (Spec. Accuracy) / ºC, < 18ºC or > 28ºC
Battery Life 250 hours typical (alkaline)
Form number TM61095 Rev 2 September 2002
