Page 4
Measurement Characteristics
Accuracy is ±(% reading + number of digits) at 23ºC ± 5ºC, less than 80% R.H.
Voltage
Function Range Accuracy Overload protection
V 600 Vrms ± (1.5%+ 3 dgt) 40Hz ~ 500Hz 600 Vrms
V 600 V ± (1% + 2 dgt)
Input impedance: 1MΩ // less than 100pF.
Resistance & Continuity
Function Range Accuracy Overload protection
Ω 2000 Ω ± (1% + 2 dgt) 600 Vrms
Max. open circuit voltage: 3V
Continuity check: Internal sounds activates if the resistance of the circuit under test is less than 25 Ω.
It will then turn off if the resistance is increased beyond 400 Ω.
AC Current
Function Range Accuracy Overload protection
A
200.0A ± (3% + 3 dgt)*45Hz ~ 66Hz 200A
* Adjacent conductor influence: <0.05 A/A
Form number TM61095 Rev 2 September 2002
