IDEAL INDUSTRIES 61-310 - Measurement Characteristics; DC Volts; AC Volts; DC Current

Form Number TM61310 Rev 2 Aug 2007
Page 4
Me
Ac
(1)
asurement Characteristics
curacy is ±(% reading + number of digits) at 23°C ± 5°C, less than 80% R.H.
DC Volts
Range Resolution Accuracy
Over voltage
protection
200.0mV 100μV
2.000V 1mV
20.00V 10mV
200.0V 100mV
0.5% + 2
600V 1V 0.8% + 2
600V rms
Inp
(2)
ut Impedance: 10MΩ
AC Volts
Range Resolution Accuracy
Over voltage
protection
40-400Hz
200.0V 100mV
1.2% + 10
600V
1V
1.2% + 10
600V rms
Input Impedance: 4.5MΩ
AC Conversion Type: Average sensing rms indication calibrated to the sine wave in put.
(3) DC Current
Resolution Accuracy Overload protection Range
200.0 mA 25 se 0.1mA 1.5% + 2 0mA/250V Fast Blow Fu
10.00A* .01A 3.0% + 5 Not fused, 15 sec Max
*
Caution: Do not make high current measurements on the 10A scale for longer that 15
ec ds s onds. This should be followed by a 15 minute cool down period. Exceeding 15 secon
may cause damage to the meter and/or the test leads.
