Ideal-Standard Waverley - Install Lever

Plastic
Washer
Rubber
Washer
Install Lever
Pull
Lever
Anti-rotation
Washer
Nut
Fixing nut
Flush
Button Box
Cistern Lever Hole
Slot In The Thread
B
B Direction
• With the lever facing outward and the
slot on the thread facing upwards, fix the
lever to cistern.
• The fixing nut should be tightened as
much as possible to avoid the cistern
lever working loose during operation.
Part
Flush
Full
Flush
