Operation
•
IDEAL 4810-95 • IDEAL 4850-95/EP • IDEAL 5221-95EP • IDEAL 6550-95EP
IDEAL 4850-95/EP, IDEAL 5221-95EP
IDEAL 6550-95/EP
The clamp moves automatically when cutting
is activated.
The paper can also be pressed in advance.
Clamping and cutting is activated by
pressing button (A) on the front table.
A
=
Pre-clamping
+
+ =
Clamp returns
+ =
Cutting sequence with automatic clamping
Only 4810-95
Clamping is released by the hand-wheel.
Before every cut lower the clamp by turning the
hand-wheel to the right and tighten with a light
twist. The cut is activated by pressing the two
buttons exactly at the same time.
- 20 -
