IDEAL 61-772 User Manual

V/
Ω
COM
CAT.IV 600V
1000V
750V
CAT.III 1000V
MAX
True RMS
OFF
400
MAX
MIN
V
1000
A
Ω
V
HOLD
CAT.IV 600V
1000A
3002010 40
PEAK
CAT.III 1000V
A
61-774
Features
1. Tapered jaws w/hook tip
2. Lever
3. Function Dial
4. Main Display (LCD)
5. Volts and resistance (V-Ω)
input terminal
6. Common (COM) input terminal
7. TightSight™ bottom display
8. Protective rubber boot
9. Measuring Functions
10. High Voltage (Hi-V) warning
11. Data Hold
12. Max/min
13. Peak max/min
14. Backlight
15. Range ( )
16. Relative mode ( )
Symbols on the Unit
• Warning - read the
instruction manual
• Cat IV - 600V Safety category
• Cat III - 1000V Safety category
Page 3
770 Series Common Features:
• Auto/manual ranging clamp meter • Large numbers and symbols displayed
• TightSight™ bottom display • Peak max/min, max/min, data hold
• Visual and audible indication when • Selectable Auto power off and low
voltage is present even when the meter battery indicator
is set on the wrong function for • Tapered jaws for reaching into tight spaces
enhanced safety • Hook tip for easier wire separation
• Measures 1000 AAC Current • Protective rubber boot
• Measures AC/DC Voltage & Resistance • Electronic overload protection on
• Audible continuity all ranges
• Bright, bold backlight • Cat IV-600V/Cat III-1000V
• 61-772 model is true rms sensing
• 61-774 model is true rms sensing, measures DC current and capacitance
1
10
11
3
15
16
4
5
9
12
13
14
6
8
7
2
