A B C Max C Min D E
Sandringham 21 1695 695 540 510 370 500
Senses 1695 695 542 500 390 450
Senses Double End 1695 745 542 500 470 470
Vue 1695 695 540 500 360 440
TECHNICAL INFORMATION
All dimensions shown in millimetres.
Dimensions shown may vary within permitted tolerances.
BEFORE YOU START
● Before commencing installation, carefully remove packaging/protective film and check for
damage. If damaged, report immediately to supplier.
● Check the packs and make sure that you have all parts listed. If not, contact the supplier.
● Ensure the water feeds and waste connection points are positioned appropriately for the
installation.
● Care should always be taken when drilling into walls and floors to avoid any sunken wires
or pipes.
● The bath should be fully protected during the installation process.
● Please note: Although these instructions are comprehensive, it is always recommended
that a technically competent installer should undertake installation.
Appropriate safety equipment/workwear should be used
The 4 black - No. 8 x 40 long countersunk crosshead
self tapping screws removed from the bath are NOT REQUIRED.
Fig. 1
To Next Page
