IDEAL ACRYLIC

Ref. F
Ref. K
Ref. E
Ref. L
Ref. G
Ref. D
Ref. J
Ref. C
Ref. B
Ref. A
Ref. H
Encapsulated
baseboard
Note: On rectangular baths,
bath legs can be installed
either way round
Use 3mm pilot holes
on all screw holes
Note: In whatever position the bath is installed
the entire bath load MUST be taken on all feet
Ref. A
Ref. B
Ref. C
Ref. J
Ref. D
Ref. E
Ref. G
Ref. G
Ref. H
Ref. K
Ref. L
Encapsulated
baseboard
tap bar
Note : For double ended baths.
To allow access to pipe work,
we recommend that the tap area
of the bath is installed
away from the wall.
BATH ASSEMBLY
Fig. 3
