HS1E Series Safety Products
B1-36 www.idec.com USA: (800) 262-IDEC or (408) 747-0550, Canada: (888) 317-IDEC
B1
Safety Products
Straight Key (mainly for sliding doors)
HS9Z-A1
L-Shaped Key (mainly for hinged doors)
HS9Z-A2
Adjustable Key
• The key angle is adjustable (0˚ to 20˚) for hinged doors.
• The minimum radius of the door opening can be as small as 100mm.
For HS1/HS2 Series (HS9Z-A3)
Accessories
2
7.4
Actuator Cover*
22
6.4
4-R3.2
30
49.3
22
2-M6
Tapped
Holes
Actuator
Mounting
Holes
weight: 22g
Key Cover*
Key
Mounting
Holes
2
4-R3.2
22
7.4
11
41.5
30
Actuator Cover*
*After installing the key, remove the key cover.
weight: 22g
Key Cover*
Stop Film
Angle Adjustment
(M3 Hexagon Socket Head Screw)
Door Hinge Side
20
5
30
R3.2
72 58
44
33 max.
12
(
21
)
1
20
°
All dimensions in mm.
