FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-89
2: P RODUCT S PECIFICATIONS
■ FC6A-R161, FC6A-R164
The two COM0 and COM1 lines are each connected in the module.
Each of the terminals for COM0 and COM1 are independent.
For wiring precautions, see "Input/Output Wiring" on page 3-18.
Screw fastened type: FC6A-R161 Push-in type: FC6A-R164
Applicable connector: FC6A-PMTC10PN02 Applicable connector: FC6A-PMSC10PN02
