BACnet Communication
The Plus CPU module can be connected to a BACnet/IP network using Ethernet port 1 and communicate with other BACnet
communication-compatible external devices. For details on BACnet communications, see the "FC6A Series MICROSmart
Communication Manual".
Supported ports
■ BACnet Communication Using Ethernet Port 1
This example shows the Plus CPU module aggregating information from Modbus RTU communication-compatible devices, communicating
with a BACnet communication-compatible device connected to a BACnet/IP network, and making that information publicly available.
USB Port Serial Port 1 Ethernet Port 1 Ethernet Port 2
Communication Cartridge and
Communication Module
CAN Port
No No Yes No No No
Ethernet Port 1
Plus CPU Module
Monitoring PC
Modbus RTU Communication
Modbus RTU
communication-compatible device
Modbus RTU
communication-compatible device
BACnet/IP Network
Lighting Device
Air Conditioning
Device
To Next Page
